Valenite M4003-100-B32-11-6.5 M4003 Face Mill, 100 mm Cutting, 32 mm Shank, 50 mm OAL, Wiper Insert, 6.5 mm Maximum Depth of Cut
Custom_Product_Images_Illustration
Valenite M4003-100-B32-11-6.5 M4003 Face Mill, 100 mm Cutting, 32 mm Shank, 50 mm OAL, Wiper Insert, 6.5 mm Maximum Depth of Cut
SKUPDW~12584421
MFGR #M4003-100-B32-11-6.5
Your Cost: $1,567.20/ea
VALENITE Face Mill, Series: M4003, 100 mm Cutting Dia, 50 mm Overall Length, 6.5 mm Maximum Depth of Cut, Wiper Insert, 11 Inserts, Insert Compatibility: SD .. 1204AZN and SDHX1204AZR, 50 mm Head Length, 32 mm Shank Dia, Cylindrical Shank, 45 deg Cutting Angle, M4003-100-B32-11-6.5, M4003-100-B32-11-6.5 ISO Code
VALENITE Face Mill, Series: M4003, 100 mm Cutting Dia, 50 mm Overall Length, 6.5 mm Maximum Depth of Cut, Wiper Insert, 11 Inserts, Insert Compatibility: SD .. 1204AZN and SDHX1204AZR, 50 mm Head Length, 32 mm Shank Dia, Cylindrical Shank, 45 deg Cutting Angle, M4003-100-B32-11-6.5, M4003-100-B32-11-6.5 ISO Code
ANSI Code M4003-100-B32-11-6.5 Catalog Number M4003-100-B32-11-6.5 Gross Weight Per Pack 2.0400 lb Head Length 50 mm ISO Code M4003-100-B32-11-6.5 Lead Angle 45 ° Series M4003-B1-SD12 Standards DIN 138 Stock Status NONSTOCK Brand Walter (Valentine) Manufacturer Walter Cutting Diameter 100 mm Insert Compatibility SD .. 1204AZN, SDHX1204AZR Insert Style SD.. Maximum Depth of Cut 6.5 mm Number of Inserts 11 Overall Length 50 mm Shank Diameter 32 mm Shank Type Shell Mill Mount 4-cutting edge per indexable insert Positive basic insert 11 Peripheral effective cutting edges Transverse keyway ISO Code: M4003-100-B32-11-6.5 ANSI Code: M4003-100-B32-11-6.5
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| ANSI Code | M4003-100-B32-11-6.5 |
| Catalog Number | M4003-100-B32-11-6.5 |
| Gross Weight Per Pack | 2.0400 lb |
| Head Length | 50 mm |
| ISO Code | M4003-100-B32-11-6.5 |
| Lead Angle | 45 ° |
| Series | M4003-B1-SD12 |
| Standards | DIN 138 |
| Stock Status | NONSTOCK |
| Brand | Walter (Valentine) |
| Manufacturer | Walter |
| Cutting Diameter | 100 mm |
| Insert Compatibility | SD .. 1204AZN, SDHX1204AZR |
| Insert Style | SD.. |
| Maximum Depth of Cut | 6.5 mm |
| Number of Inserts | 11 |
| Overall Length | 50 mm |
| Shank Diameter | 32 mm |
| Shank Type | Shell Mill Mount |
| 4-cutting edge per indexable insert |
| Positive basic insert |
| 11 Peripheral effective cutting edges |
| Transverse keyway |
| ISO Code: M4003-100-B32-11-6.5 |
| ANSI Code: M4003-100-B32-11-6.5 |
