Turck powerfast™ BSMV BKMV 22-380-5 Double Ended Cordset, M16 x 0.75 Straight Male x Straight Female Connector, 2 Poles
Turck powerfast™ BSMV BKMV 22-380-5 Double Ended Cordset, M16 x 0.75 Straight Male x Straight Female Connector, 2 Poles
SKUPDW~10011689
MFGR #U-60218
$/ea
Turck powerfast™ Cordset, Double Ended, Straight Male x Straight Female Connector, M16 x 0.75 Connector, Stainless Steel, 2 m Cable Length, PVC Cable, 2 Pole, 600 VAC, 18 A, White/Black Wire Pin Colors, IP67 IEC Rating
Turck powerfast™ Cordset, Double Ended, Straight Male x Straight Female Connector, M16 x 0.75 Connector, Stainless Steel, 2 m Cable Length, PVC Cable, 2 Pole, 600 VAC, 18 A, White/Black Wire Pin Colors, IP67 IEC Rating
Amperage Rating 18 A Cable Material PVC Catalog Number U-60218 Connector Material Stainless Steel Gross Weight Per Pack 1 lb IEC Rating IP67 Length [Metric] 2 m NEMA Rating NEMA IP67 Number Of Poles 2 Returnable N Standards RoHS Complaint, UL Listed Type Double End Voltage Rating 600 VAC Wire Pin Colors Black/White Stock Status NONSTOCK Brand Turck Manufacturer Turck, Inc. Cable Length 2 m Connector Size M16x0.75 Connector Type Straight Male x Straight Female 2 conductors 12 AWG black cable Black TPU contact carrier TPU molded head material Gold plated brass/TeCu contact material Passivated stainless steel coupling nut Black PVC outer jacket material PVC/nylon conductor insulation material -40 to 90 deg C temperature
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Amperage Rating | 18 A |
| Cable Material | PVC |
| Catalog Number | U-60218 |
| Connector Material | Stainless Steel |
| Gross Weight Per Pack | 1 lb |
| IEC Rating | IP67 |
| Length [Metric] | 2 m |
| NEMA Rating | NEMA IP67 |
| Number Of Poles | 2 |
| Returnable | N |
| Standards | RoHS Complaint, UL Listed |
| Type | Double End |
| Voltage Rating | 600 VAC |
| Wire Pin Colors | Black/White |
| Stock Status | NONSTOCK |
| Brand | Turck |
| Manufacturer | Turck, Inc. |
| Cable Length | 2 m |
| Connector Size | M16x0.75 |
| Connector Type | Straight Male x Straight Female |
| 2 conductors |
| 12 AWG black cable |
| Black TPU contact carrier |
| TPU molded head material |
| Gold plated brass/TeCu contact material |
| Passivated stainless steel coupling nut |
| Black PVC outer jacket material |
| PVC/nylon conductor insulation material |
| -40 to 90 deg C temperature |
