Turck picofast® PKGS 4M-20-PKGS 4M/S90/S1307 Double Ended Cordset, M8 x 1 Straight Female x Straight Female Connector
Turck picofast® PKGS 4M-20-PKGS 4M/S90/S1307 Double Ended Cordset, M8 x 1 Straight Female x Straight Female Connector
SKUPDW~11213873
MFGR #U-81612
$/ea
Turck picofast® Cordset, Double Ended, Straight Female x Straight Female Connector, M8 x 1 Connector, Brass, Shielded/Braid Cable, 20 m Cable Length, PVC Cable, 4 Pole, 125 VAC/VDC, 2 A, Brown/White/Blue/Black Wire Pin Colors, IP67
Turck picofast® Cordset, Double Ended, Straight Female x Straight Female Connector, M8 x 1 Connector, Brass, Shielded/Braid Cable, 20 m Cable Length, PVC Cable, 4 Pole, 125 VAC/VDC, 2 A, Brown/White/Blue/Black Wire Pin Colors, IP67
Amperage Rating 2 A Cable Material PVC Cable Type Braided/Shielded Catalog Number U-81612 Connector Material Brass Gross Weight Per Pack 1 lb Length [Metric] 20 m NEMA Rating NEMA IP67 Number Of Poles 4 Returnable N Type Double End Voltage Rating 125 VAC/VDC Wire Pin Colors Black/Blue/Brown/White Stock Status NONSTOCK Brand Turck Manufacturer Turck, Inc. Cable Length 20 m Connector Size M8 Connector Type Straight Female 26 AWG yellow cable, 28 AWG/aluminum-polyester foil, tinned copper braid Nylon or TPU contact carrier material Brass/gold contact material/plating Brass/nickel coupling nut material/plating -40 to 105 deg C operating temperature
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Amperage Rating | 2 A |
| Cable Material | PVC |
| Cable Type | Braided/Shielded |
| Catalog Number | U-81612 |
| Connector Material | Brass |
| Gross Weight Per Pack | 1 lb |
| Length [Metric] | 20 m |
| NEMA Rating | NEMA IP67 |
| Number Of Poles | 4 |
| Returnable | N |
| Type | Double End |
| Voltage Rating | 125 VAC/VDC |
| Wire Pin Colors | Black/Blue/Brown/White |
| Stock Status | NONSTOCK |
| Brand | Turck |
| Manufacturer | Turck, Inc. |
| Cable Length | 20 m |
| Connector Size | M8 |
| Connector Type | Straight Female |
| 26 AWG yellow cable, 28 AWG/aluminum-polyester foil, tinned copper braid |
| Nylon or TPU contact carrier material |
| Brass/gold contact material/plating |
| Brass/nickel coupling nut material/plating |
| -40 to 105 deg C operating temperature |
