Turck multifast® CSMV CKWMV 19-19-8 Double Ended Cordset, M23 x 1 Straight Male x Right Angle Female Connector
Turck multifast® CSMV CKWMV 19-19-8 Double Ended Cordset, M23 x 1 Straight Male x Right Angle Female Connector
SKUPDW~12216055
MFGR #U-38813
$/ea
Turck multifast® Cordset, Double Ended, Straight Male x Right Angle Female Connector, M23 x 1 Connector, Stainless Steel, Shielded Cable, 8 m Cable Length, PVC Cable, 19 Pole, 150 VAC, 9 A, Violet/Red/Gray/Red/Blue/Green/Blue/Gray/Pink/White/Green/White/Yellow/White/Gray/Black/Green/Yellow/Yellow/Brown/Brown/Green/White/Yellow/Pink/Gray/ Brown/Brown Wire Pin Colors, IP67 IEC Rating
Turck multifast® Cordset, Double Ended, Straight Male x Right Angle Female Connector, M23 x 1 Connector, Stainless Steel, Shielded Cable, 8 m Cable Length, PVC Cable, 19 Pole, 150 VAC, 9 A, Violet/Red/Gray/Red/Blue/Green/Blue/Gray/Pink/White/Green/White/Yellow/White/Gray/Black/Green/Yellow/Yellow/Brown/Brown/Green/White/Yellow/Pink/Gray/ Brown/Brown Wire Pin Colors, IP67 IEC Rating
Amperage Rating 9 A Cable Material PVC Cable Type Shielded Catalog Number U-38813 Connector Material Stainless Steel Gross Weight Per Pack 1 lb IEC Rating IP67 Length [Metric] 8 m Number Of Poles 19 Returnable N Standards UL Listed Type Double Ended Voltage Rating 150 VAC Wire Pin Colors Violet/Red/Gray/Red/Blue/Green/Blue/Gray/Pink/White/Green/White/Yellow/White/Gray/Black/Green/Yellow/Yellow/Brown/Brown/Green/White/Yellow/Pink/Gray/ Brown/Brown Stock Status NONSTOCK Brand Turck Manufacturer Turck, Inc. Cable Length 8 m Connector Size M23 Connector Type Straight Male x Right Angle Female 19 conductors 18 and 22 AWG yellow cable Nylon or PBT contact carriers Black TPU molded head material Gold plated brass contact material Passivated finish stainless steel coupling nut Yellow PVC cable jacket material PVC conductor insulation material 20 AWG drain/polyester foil shield -40 to 105 deg C operating
content loaded
content loaded
content loaded
- Attributes
- Features
- Substitute Products
| Amperage Rating | 9 A |
| Cable Material | PVC |
| Cable Type | Shielded |
| Catalog Number | U-38813 |
| Connector Material | Stainless Steel |
| Gross Weight Per Pack | 1 lb |
| IEC Rating | IP67 |
| Length [Metric] | 8 m |
| Number Of Poles | 19 |
| Returnable | N |
| Standards | UL Listed |
| Type | Double Ended |
| Voltage Rating | 150 VAC |
| Wire Pin Colors | Violet/Red/Gray/Red/Blue/Green/Blue/Gray/Pink/White/Green/White/Yellow/White/Gray/Black/Green/Yellow/Yellow/Brown/Brown/Green/White/Yellow/Pink/Gray/ Brown/Brown |
| Stock Status | NONSTOCK |
| Brand | Turck |
| Manufacturer | Turck, Inc. |
| Cable Length | 8 m |
| Connector Size | M23 |
| Connector Type | Straight Male x Right Angle Female |
| 19 conductors |
| 18 and 22 AWG yellow cable |
| Nylon or PBT contact carriers |
| Black TPU molded head material |
| Gold plated brass contact material |
| Passivated finish stainless steel coupling nut |
| Yellow PVC cable jacket material |
| PVC conductor insulation material |
| 20 AWG drain/polyester foil shield |
| -40 to 105 deg C operating |
