Turck
Turck minifast® RSM RKM 579-14M Double Ended Cordset, 7/8-16 UN Straight Male x Straight Female Connector, 14 m L Cable
Turck
Turck minifast® RSM RKM 579-14M Double Ended Cordset, 7/8-16 UN Straight Male x Straight Female Connector, 14 m L Cable
SKU702417
MFGR #U5450-574
Your Cost: $241.53/ea
Turck minifast® Cordset, Double Ended, Straight Male x Straight Female Connector, 7/8-16 UN Connector, Brass, 14 m Cable Length, PVC Cable, 5 Pole, 300 VAC, 9 A, Bare/Red/Black/White/Blue Wire Pin Colors, NEMA 1/3/4/6P/IP67
Turck minifast® Cordset, Double Ended, Straight Male x Straight Female Connector, 7/8-16 UN Connector, Brass, 14 m Cable Length, PVC Cable, 5 Pole, 300 VAC, 9 A, Bare/Red/Black/White/Blue Wire Pin Colors, NEMA 1/3/4/6P/IP67
Amperage Rating 9 A Cable Material PVC Catalog Number U5450-574 Connector Material Brass Gross Weight Per Pack 1 lb Length [Metric] 14 m NEMA Rating NEMA 1/3/4/6P/IP67 Number Of Poles 5 Returnable N Standards UL Listed, FM Div.2, CSA Certified, CSA PA Certified, RoHS Compliant Type Double End Voltage Rating 300 VAC Wire Pin Colors Black/Blue/Red/White Stock Status NONSTOCK Brand Turck Manufacturer Turck, Inc. Cable Length 14 m Connector Size 7/8-16 UN Connector Type Straight Male x Straight Female Gray cable jacket color Nickel plated Brass coupling nut Gold plated brass contact material 2 x 15 AWG, 2 x 18 AWG color code, 18 AWG drain TPU, blue/gray contact carrier and molded head material -40 to 80 deg C operating temperature PE data, SRPVC power conductor insulation 5 conductors
content loaded
content loaded
content loaded
- Attributes
- Features
- Substitute Products
| Amperage Rating | 9 A |
| Cable Material | PVC |
| Catalog Number | U5450-574 |
| Connector Material | Brass |
| Gross Weight Per Pack | 1 lb |
| Length [Metric] | 14 m |
| NEMA Rating | NEMA 1/3/4/6P/IP67 |
| Number Of Poles | 5 |
| Returnable | N |
| Standards | UL Listed, FM Div.2, CSA Certified, CSA PA Certified, RoHS Compliant |
| Type | Double End |
| Voltage Rating | 300 VAC |
| Wire Pin Colors | Black/Blue/Red/White |
| Stock Status | NONSTOCK |
| Brand | Turck |
| Manufacturer | Turck, Inc. |
| Cable Length | 14 m |
| Connector Size | 7/8-16 UN |
| Connector Type | Straight Male x Straight Female |
| Gray cable jacket color |
| Nickel plated Brass coupling nut |
| Gold plated brass contact material |
| 2 x 15 AWG, 2 x 18 AWG color code, 18 AWG drain |
| TPU, blue/gray contact carrier and molded head material |
| -40 to 80 deg C operating temperature |
| PE data, SRPVC power conductor insulation |
| 5 conductors |
