Turck
Turck minifast® P-RSV RKV 63-1909-25M Double Ended Cordset, 7/8-16 UN Straight Male x Straight Female Connector
Turck
Turck minifast® P-RSV RKV 63-1909-25M Double Ended Cordset, 7/8-16 UN Straight Male x Straight Female Connector
SKU805099
MFGR #U-51001
$/ea
Turck minifast® Cordset, Double Ended, Straight Male x Straight Female Connector, 7/8-16 UN Connector, Stainless Steel, 25 m Cable Length, PVC Cable, 6 Pole, 600 VAC, 8 A, White/Red/Green/Orange/Black/Blue Wire Pin Colors, IP67 IEC Rating, NEMA 1/3/4/6P
Turck minifast® Cordset, Double Ended, Straight Male x Straight Female Connector, 7/8-16 UN Connector, Stainless Steel, 25 m Cable Length, PVC Cable, 6 Pole, 600 VAC, 8 A, White/Red/Green/Orange/Black/Blue Wire Pin Colors, IP67 IEC Rating, NEMA 1/3/4/6P
Amperage Rating 8 A Cable Material PVC Catalog Number U-51001 Connector Material Stainless Steel Gross Weight Per Pack 1 lb IEC Rating IP67 Length [Metric] 25 m NEMA Rating NEMA 1/3/4/6P Number Of Poles 6 Returnable N Standards CSA, CSA PA, FM Division 2 Certified, UL Listed Type Double Ended Voltage Rating 600 VAC Wire Pin Colors White/Red/Green/Orange/Black/Blue Stock Status NONSTOCK Brand Turck Manufacturer Turck, Inc. Cable Length 25 m Connector Size 7/8-16 UN Connector Type Straight Male x Straight Female 6 conductors 16 AWG blue cable TPU contact carrier Black TPU molded head material Gold plated brass contact material Passivated stainless steel coupling nut Blue PVC outer jacket material PVC/nylon conductor insulation material -40 to 105 deg C operating
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Amperage Rating | 8 A |
| Cable Material | PVC |
| Catalog Number | U-51001 |
| Connector Material | Stainless Steel |
| Gross Weight Per Pack | 1 lb |
| IEC Rating | IP67 |
| Length [Metric] | 25 m |
| NEMA Rating | NEMA 1/3/4/6P |
| Number Of Poles | 6 |
| Returnable | N |
| Standards | CSA, CSA PA, FM Division 2 Certified, UL Listed |
| Type | Double Ended |
| Voltage Rating | 600 VAC |
| Wire Pin Colors | White/Red/Green/Orange/Black/Blue |
| Stock Status | NONSTOCK |
| Brand | Turck |
| Manufacturer | Turck, Inc. |
| Cable Length | 25 m |
| Connector Size | 7/8-16 UN |
| Connector Type | Straight Male x Straight Female |
| 6 conductors |
| 16 AWG blue cable |
| TPU contact carrier |
| Black TPU molded head material |
| Gold plated brass contact material |
| Passivated stainless steel coupling nut |
| Blue PVC outer jacket material |
| PVC/nylon conductor insulation material |
| -40 to 105 deg C operating |
