Turck RJ45 RJ45 442-90M/C1195 Double Ended Cordset, Straight Female Connector, 90 m L Cable, 4 Poles
Quick Connect Cable Assemblies
PDW~12232223
MFG #: U-29528
Turck
0.00000
/ ea
Turck offers a complete line of molded Industrial Ethernet cordsets to facilitate network installation, resulting in faster start-up and fewer wiring errors. These robust cables are available with stranded or solid-core conductors, and with or without shielding. Most Turck Ethernet equipment uses the 4 or 8-pin (M12) eurofast® connector specifications. These connectors provide a tough, rugged seal and are IP67-rated. Turck provides RJ45 cordsets, as well as a variety of devices made to convert betweenRJ45 and Eurofast connectors. Turck cordsets for the Ethernet system are available in standard lengths, in addition to custom lengths through the companys sales representatives.
- Features
4 conductors |
24 AWG solid teal cable |
Polycarbonate contact carrier |
Black TPU molded head material |
Gold plated bronze contact material |
Teal TPU outer cable jacket material |
HDPE conductor insulation material |
-40 to 75 deg C operating |
EtherNet fieldbus protocol |
