Turck Eurofast® RKC 8T-15-RKC8T/S101 Double Ended Cordset, M12 x 1 Straight Female x Straight Male Connector, 8 Poles
Turck Eurofast® RKC 8T-15-RKC8T/S101 Double Ended Cordset, M12 x 1 Straight Female x Straight Male Connector, 8 Poles
SKUPDW~11214941
MFGR #U-76607
$/ea
Turck Eurofast® Cordset, Double Ended, Straight Female x Straight Male Connector, M12 x 1 Connector, 15 m Cable Length, TPE Cable, 8 Pole, 60 VAC/75 VDC, 2 A, White/Brown/Green/Yellow/Gray/Pink/Blue/Red Wire Pin Colors, IP68/IP69K IEC Rating, NEMA 1/3/4/6P
Turck Eurofast® Cordset, Double Ended, Straight Female x Straight Male Connector, M12 x 1 Connector, 15 m Cable Length, TPE Cable, 8 Pole, 60 VAC/75 VDC, 2 A, White/Brown/Green/Yellow/Gray/Pink/Blue/Red Wire Pin Colors, IP68/IP69K IEC Rating, NEMA 1/3/4/6P
Amperage Rating 2 A Cable Material TPE Catalog Number U-76607 Gross Weight Per Pack 1 lb IEC Rating IP68/IP69K Length [Metric] 15 m NEMA Rating NEMA 1/3/4/6P Number Of Poles 8 Returnable N Type Double Ended Voltage Rating 60 VAC/75 VDC Wire Pin Colors White/Brown/Green/Yellow/Gray/Pink/Blue/Red Stock Status NONSTOCK Brand Turck Manufacturer Turck, Inc. Cable Length 15 m Connector Size M12 Connector Type Straight Female x Straight Male 8 conductors 24 AWG gray cable Nylon TPU contact carriers Yellow TPU molded head material Gold plated brass contact material Nickel plated brass coupling nut Polyester elastomer conductor insulation material -40 to 105 deg C operating
content loaded
content loaded
content loaded
- Attributes
- Features
- Substitute Products
| Amperage Rating | 2 A |
| Cable Material | TPE |
| Catalog Number | U-76607 |
| Gross Weight Per Pack | 1 lb |
| IEC Rating | IP68/IP69K |
| Length [Metric] | 15 m |
| NEMA Rating | NEMA 1/3/4/6P |
| Number Of Poles | 8 |
| Returnable | N |
| Type | Double Ended |
| Voltage Rating | 60 VAC/75 VDC |
| Wire Pin Colors | White/Brown/Green/Yellow/Gray/Pink/Blue/Red |
| Stock Status | NONSTOCK |
| Brand | Turck |
| Manufacturer | Turck, Inc. |
| Cable Length | 15 m |
| Connector Size | M12 |
| Connector Type | Straight Female x Straight Male |
| 8 conductors |
| 24 AWG gray cable |
| Nylon TPU contact carriers |
| Yellow TPU molded head material |
| Gold plated brass contact material |
| Nickel plated brass coupling nut |
| Polyester elastomer conductor insulation material |
| -40 to 105 deg C operating |
