Turck
Turck Eurofast® RJ45S RJ45S 441-20M Double Ended Cordset, RJ45 Straight Female x Straight Female Connector, 20 m L Cable
Turck
Turck Eurofast® RJ45S RJ45S 441-20M Double Ended Cordset, RJ45 Straight Female x Straight Female Connector, 20 m L Cable
SKU604338
MFGR #U-04692
$/ea
Turck offers a complete line of molded Industrial Ethernet cord sets to facilitate network installation, resulting in faster start-up and fewer wiring errors. These robust cables are available with stranded or solid-core conductors, and with or without shielding. Most Turck Ethernet equipment uses the 4 or 8-pin (M12) eurofast® connector specifications. These connectors provide a tough, rugged seal and are IP67-rated. Turck provides RJ45 cord sets, as well as a variety of devices made to convert between RJ45 and Eurofast connectors. Turck cord sets for the Ethernet system are available in standard lengths, in addition to custom lengths through the company?s sales representatives.
Turck offers a complete line of molded Industrial Ethernet cord sets to facilitate network installation, resulting in faster start-up and fewer wiring errors. These robust cables are available with stranded or solid-core conductors, and with or without shielding. Most Turck Ethernet equipment uses the 4 or 8-pin (M12) eurofast® connector specifications. These connectors provide a tough, rugged seal and are IP67-rated. Turck provides RJ45 cord sets, as well as a variety of devices made to convert between RJ45 and Eurofast connectors. Turck cord sets for the Ethernet system are available in standard lengths, in addition to custom lengths through the company?s sales representatives.
Amperage Rating 1.5 A Cable Material PVC Cable Type Shielded Catalog Number U-04692 Connector Material Bronze Gross Weight Per Pack 1 lb Length [Metric] 20 m NEMA Rating NEMA IP20 Number Of Poles 4 Returnable Y Standards UL E464271 Listed, ODVA, EIA/TIA 568-C.2 and ISO/IEC standards, RoHS Compalint Type Double End Voltage Rating 42 VAC Wire Pin Colors Green/Orange/White Stock Status NONSTOCK Brand Turck Manufacturer Turck, Inc. Cable Length 20 m Connector Size RJ45 Connector Type Straight Female Turck Ethernet stranded cables meet full CAT 5e performance to 85 meter length Turck Ethernet cables are PoE (Power over Ethernet) and PoE compliant, per IEEE 802.3 at, to 80 meters, when installed per recommendations in TIA TSB-184 Turck Ethernet cable type 444 is ITC rated and approved for use in C1D2 (hazardous location) environments when used with our 4-pin D-code M12 Gigabit Ethernet (X-code) options available Excellent oil resistance (including lubricant used in most robot dress packs) Excellent moisture resistance Good ozone resistance Excellent UV and weathering resistance Excellent weld spatter resistance Very good flame retardant High flexing up to 10 million cycles for stranded cable Low temperature brittle point Polycarbonate/clear contact carrier material/color TUP/black molded head material color Bronze/gold contact material/plating HDPE conductor insulation material Aluminum foil and tinned copper braided shielding 24 AWG teal, Cat 5e cable -40 to 75 deg C operating temperature
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Amperage Rating | 1.5 A |
| Cable Material | PVC |
| Cable Type | Shielded |
| Catalog Number | U-04692 |
| Connector Material | Bronze |
| Gross Weight Per Pack | 1 lb |
| Length [Metric] | 20 m |
| NEMA Rating | NEMA IP20 |
| Number Of Poles | 4 |
| Returnable | Y |
| Standards | UL E464271 Listed, ODVA, EIA/TIA 568-C.2 and ISO/IEC standards, RoHS Compalint |
| Type | Double End |
| Voltage Rating | 42 VAC |
| Wire Pin Colors | Green/Orange/White |
| Stock Status | NONSTOCK |
| Brand | Turck |
| Manufacturer | Turck, Inc. |
| Cable Length | 20 m |
| Connector Size | RJ45 |
| Connector Type | Straight Female |
| Turck Ethernet stranded cables meet full CAT 5e performance to 85 meter length |
| Turck Ethernet cables are PoE (Power over Ethernet) and PoE compliant, per IEEE 802.3 at, to 80 meters, when installed per recommendations in TIA TSB-184 |
| Turck Ethernet cable type 444 is ITC rated and approved for use in C1D2 (hazardous location) environments when used with our 4-pin D-code M12 |
| Gigabit Ethernet (X-code) options available |
| Excellent oil resistance (including lubricant used in most robot dress packs) |
| Excellent moisture resistance |
| Good ozone resistance |
| Excellent UV and weathering resistance |
| Excellent weld spatter resistance |
| Very good flame retardant |
| High flexing up to 10 million cycles for stranded cable |
| Low temperature brittle point |
| Polycarbonate/clear contact carrier material/color |
| TUP/black molded head material color |
| Bronze/gold contact material/plating |
| HDPE conductor insulation material |
| Aluminum foil and tinned copper braided shielding |
| 24 AWG teal, Cat 5e cable |
| -40 to 75 deg C operating temperature |
