Telemecanique Sensors
Telemecanique ZCMD21C12 OsiSense® Limit Switch Body, 1NO-1NC
Custom_Product_Images_Illustration
Telemecanique Sensors
Telemecanique ZCMD21C12 OsiSense® Limit Switch Body, 1NO-1NC
SKU308304
MFGR #ZCMD21C12
Your Cost: $99.12/ea
Telemecanique Sensors ZCMD21C12 LIMIT SWITCH 24VAC 4A METAL ZCMD,1 NC + 1 NO,4 A,IEC, UL listed, CSA,Male connector M12, 5 pins,OsiSense,OsiSense XC,fixed,limit switch body,XCMD,ZCMD,ZCMD,standard format,fixed,fixed
Telemecanique Sensors ZCMD21C12 LIMIT SWITCH 24VAC 4A METAL ZCMD,1 NC + 1 NO,4 A,IEC, UL listed, CSA,Male connector M12, 5 pins,OsiSense,OsiSense XC,fixed,limit switch body,XCMD,ZCMD,ZCMD,standard format,fixed,fixed
Action Snap action Alternate Catalog Number ZCMD21C12 Amperage Rating 4 A Application XCMD ARRA Compliant N Brand Telemecanique Sensors Buy American Compliant N Catalog Number ZCMD21C12 Closed Contact Resistance 25 MOHM IEC 60255-7 CATEGORY 3 Connection MALE CONNECTOR M12, 5 PINS Connection Type 5-Pin M12 Male Connector Contact Configuration 1NO-1NC Contact Rating 4 A Country of Origin US Currency USD Dimensions 1.97 in H x 1.18 in W x 0.63 in D EU RoHS Indicator Y Gross Volume Per Pack 2.94 Gross Volume per Pack Metric 48.18 Gross Volume UOM CI Gross Volume UOM Metric cm3 Gross Weight Per Pack 0.1700 lb Gross Weight per Pack Metric 78.00 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8536509055 Height 2.0000 in Height [Metric] 2.0000 cm Item Group 22413 Length 8.0000 in Length [Metric] 8.0000 cm Manufacturer Telemecanique Sensors Material Zamak Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=880298&lang=en-us Number Of Poles 2 Returnable Y Series ZCMD Size 16 MM,30 MM,50-50 MM Standard IEC, UL LISTED, CSA Stock Status NONSTOCK Sub Brand ZCMD Suitable For Use With XCMD and ZCMD Series Standard Format Limit Switch Temperature Rating -40 to 158 °F Type 2-Pole Fixed UNSPSC 39122213 UPC 11 78590163038 UPC 12 785901630388 Voltage Rating 0.22 A 50 V, DC-13 EN/IEC 60947-5-1 APPENDIX A-3 A 50 V, AC-15 EN/IEC 60947-5-1 APPENDIX A Warranty Description Contractual Warranty:18 months Width 6.0000 in Width [Metric] 6.0000 cm XCMD FIXED 2 pole Snap action Silver plated contacts <25 MOhm resistance across terminals 5000000 operating cycles -40 to 158 deg F ambient air temperature for storage
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Action | Snap action |
| Alternate Catalog Number | ZCMD21C12 |
| Amperage Rating | 4 A |
| Application | XCMD |
| ARRA Compliant | N |
| Brand | Telemecanique Sensors |
| Buy American Compliant | N |
| Catalog Number | ZCMD21C12 |
| Closed Contact Resistance | 25 MOHM IEC 60255-7 CATEGORY 3 |
| Connection | MALE CONNECTOR M12, 5 PINS |
| Connection Type | 5-Pin M12 Male Connector |
| Contact Configuration | 1NO-1NC |
| Contact Rating | 4 A |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 1.97 in H x 1.18 in W x 0.63 in D |
| EU RoHS Indicator | Y |
| Gross Volume Per Pack | 2.94 |
| Gross Volume per Pack Metric | 48.18 |
| Gross Volume UOM | CI |
| Gross Volume UOM Metric | cm3 |
| Gross Weight Per Pack | 0.1700 lb |
| Gross Weight per Pack Metric | 78.00 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8536509055 |
| Height | 2.0000 in |
| Height [Metric] | 2.0000 cm |
| Item Group | 22413 |
| Length | 8.0000 in |
| Length [Metric] | 8.0000 cm |
| Manufacturer | Telemecanique Sensors |
| Material | Zamak |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=880298&lang=en-us |
| Number Of Poles | 2 |
| Returnable | Y |
| Series | ZCMD |
| Size | 16 MM,30 MM,50-50 MM |
| Standard | IEC, UL LISTED, CSA |
| Stock Status | NONSTOCK |
| Sub Brand | ZCMD |
| Suitable For Use With | XCMD and ZCMD Series Standard Format Limit Switch |
| Temperature Rating | -40 to 158 °F |
| Type | 2-Pole Fixed |
| UNSPSC | 39122213 |
| UPC 11 | 78590163038 |
| UPC 12 | 785901630388 |
| Voltage Rating | 0.22 A 50 V, DC-13 EN/IEC 60947-5-1 APPENDIX A-3 A 50 V, AC-15 EN/IEC 60947-5-1 APPENDIX A |
| Warranty Description | Contractual Warranty:18 months |
| Width | 6.0000 in |
| Width [Metric] | 6.0000 cm |
| XCMD |
| FIXED |
| 2 pole |
| Snap action |
| Silver plated contacts |
| <25 MOhm resistance across terminals |
| 5000000 operating cycles |
| -40 to 158 deg F ambient air temperature for storage |
