Telemecanique ZCKL1 OsiSense® Limit Switch Body, 1NO-1NC
Custom_Product_Images_Illustration
Telemecanique ZCKL1 OsiSense® Limit Switch Body, 1NO-1NC
SKU34138
MFGR #ZCKL1
Your Cost: $145.40/ea
Telemecanique Sensors ZCKL1 LIMIT SW BODY SNAP DOUBLE BRK 1NO/NC 1P,-25...70 deg.C for standard environment,1 NC + 1 NO,1 tapped entry for Pg 13.5 cable gland (included),fixed,10 A,300 V (CSA, UL) 500 V (IEC),IEC, UL listed, CSA,IP66,OsiSense,OsiSense XC,fixed,limit switch body,Screw-clamp terminals,XCKL,ZCKL,ZCKL,standard format,fixed,standard environment
Telemecanique Sensors ZCKL1 LIMIT SW BODY SNAP DOUBLE BRK 1NO/NC 1P,-25...70 deg.C for standard environment,1 NC + 1 NO,1 tapped entry for Pg 13.5 cable gland (included),fixed,10 A,300 V (CSA, UL) 500 V (IEC),IEC, UL listed, CSA,IP66,OsiSense,OsiSense XC,fixed,limit switch body,Screw-clamp terminals,XCKL,ZCKL,ZCKL,standard format,fixed,standard environment
Action Snap action Alternate Catalog Number ZCKL1 Amperage Rating 10 A Application XCKL ARRA Compliant N Brand Telemecanique Sensors Buy American Compliant N Catalog Number ZCKL1 Closed Contact Resistance 0.25 MOHM IEC 60255-7 CATEGORY 3 Connection SCREW-CLAMP TERMINALS 1 X 0.34...2 X 1.5 MMA² Connection Type Screw Clamp Contact Configuration 1NO-1NC Contact Rating 10 A, 500 VAC Country of Origin FR Currency USD Dimensions 2.83 in H x 2.05 in W x 1.18 in D Enclosure IP66 Enclosure Type IP66 Environmental Conditions STANDARD ENVIRONMENT EU RoHS Indicator Y Gross Volume Per Pack 10.82 Gross Volume per Pack Metric 177.31 Gross Volume UOM CI Gross Volume UOM Metric cm3 Gross Weight Per Pack 0.4900 lb Gross Weight per Pack Metric 223.00 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8536509055 Height 3.3000 in Height [Metric] 3.3000 cm Item Group 22416 Length 8.0000 in Length [Metric] 8.0000 cm Manufacturer Telemecanique Sensors Material Metal Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=879818&lang=en-us Number Of Poles 2 Operating Temperature -25-70 A°C STANDARD ENVIRONMENT Returnable Y Series ZCKJ Size 1.18 in Standard IK05,IP66 Standards REACH, RoHS Compliant Stock Status NONSTOCK Sub Brand ZCKL Suitable For Use With XCKJ and ZCKJ Limit Switch Temperature Rating -25 to 70 °C Type Standard UNSPSC 39122213 UPC 11 78590164666 UPC 12 785901646662 Voltage Rating 3 A 240 V, AC-15, A300 EN/IEC 60947-5-1 APPENDIX A-0.27 A 250 V, DC-13, Q300 EN/IEC 60947-5-1 APPENDIX A Warranty Description Contractual Warranty:18 months Width 6.5000 in Width [Metric] 6.5000 cm XCKL FIXED 1 x 0.34 to 2 x 1.5 sq-mm clamping capacity 1 entry tapped for cable gland 2 pole Snap action Silver plated contacts 0.01 m/min actuation speed 0.25 mOhm resistance across terminals 5000000 operating cycles 10 A current
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Action | Snap action |
| Alternate Catalog Number | ZCKL1 |
| Amperage Rating | 10 A |
| Application | XCKL |
| ARRA Compliant | N |
| Brand | Telemecanique Sensors |
| Buy American Compliant | N |
| Catalog Number | ZCKL1 |
| Closed Contact Resistance | 0.25 MOHM IEC 60255-7 CATEGORY 3 |
| Connection | SCREW-CLAMP TERMINALS 1 X 0.34...2 X 1.5 MMA² |
| Connection Type | Screw Clamp |
| Contact Configuration | 1NO-1NC |
| Contact Rating | 10 A, 500 VAC |
| Country of Origin | FR |
| Currency | USD |
| Dimensions | 2.83 in H x 2.05 in W x 1.18 in D |
| Enclosure | IP66 |
| Enclosure Type | IP66 |
| Environmental Conditions | STANDARD ENVIRONMENT |
| EU RoHS Indicator | Y |
| Gross Volume Per Pack | 10.82 |
| Gross Volume per Pack Metric | 177.31 |
| Gross Volume UOM | CI |
| Gross Volume UOM Metric | cm3 |
| Gross Weight Per Pack | 0.4900 lb |
| Gross Weight per Pack Metric | 223.00 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8536509055 |
| Height | 3.3000 in |
| Height [Metric] | 3.3000 cm |
| Item Group | 22416 |
| Length | 8.0000 in |
| Length [Metric] | 8.0000 cm |
| Manufacturer | Telemecanique Sensors |
| Material | Metal |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=879818&lang=en-us |
| Number Of Poles | 2 |
| Operating Temperature | -25-70 A°C STANDARD ENVIRONMENT |
| Returnable | Y |
| Series | ZCKJ |
| Size | 1.18 in |
| Standard | IK05,IP66 |
| Standards | REACH, RoHS Compliant |
| Stock Status | NONSTOCK |
| Sub Brand | ZCKL |
| Suitable For Use With | XCKJ and ZCKJ Limit Switch |
| Temperature Rating | -25 to 70 °C |
| Type | Standard |
| UNSPSC | 39122213 |
| UPC 11 | 78590164666 |
| UPC 12 | 785901646662 |
| Voltage Rating | 3 A 240 V, AC-15, A300 EN/IEC 60947-5-1 APPENDIX A-0.27 A 250 V, DC-13, Q300 EN/IEC 60947-5-1 APPENDIX A |
| Warranty Description | Contractual Warranty:18 months |
| Width | 6.5000 in |
| Width [Metric] | 6.5000 cm |
| XCKL |
| FIXED |
| 1 x 0.34 to 2 x 1.5 sq-mm clamping capacity |
| 1 entry tapped for cable gland |
| 2 pole |
| Snap action |
| Silver plated contacts |
| 0.01 m/min actuation speed |
| 0.25 mOhm resistance across terminals |
| 5000000 operating cycles |
| 10 A current |
