Telemecanique Sensors
Telemecanique XCSDMC590L01M8 Preventa™ 3-Direction 2-Pole Safety Interlock Switch, Coded Magnetic Actuator, 100 mA at 24 VDC Contact, 1NC-1NO Contact, Rhodium Contact
Custom_Product_Images_Illustration
Telemecanique Sensors
Telemecanique XCSDMC590L01M8 Preventa™ 3-Direction 2-Pole Safety Interlock Switch, Coded Magnetic Actuator, 100 mA at 24 VDC Contact, 1NC-1NO Contact, Rhodium Contact
SKU796366
MFGR #XCSDMC590L01M8
Your Cost: $143.04/ea
Telemecanique Preventa™ Safety Interlock Switch, 3-Direction 2-Pole, Series: XCSDMC, Compact/Rectangular Style, Coded Magnetic Actuator, 100 mA at 24 VDC Contact, 1NC-1NO Contact Configuration, Rhodium Contact, M8 Flying Lead Connection, 0.15 m Cable Length, IP67 Enclosure, Thermoplastic, Red, 51 mm H x 16 mm W x 7 mm D Dimensions
Telemecanique Preventa™ Safety Interlock Switch, 3-Direction 2-Pole, Series: XCSDMC, Compact/Rectangular Style, Coded Magnetic Actuator, 100 mA at 24 VDC Contact, 1NC-1NO Contact Configuration, Rhodium Contact, M8 Flying Lead Connection, 0.15 m Cable Length, IP67 Enclosure, Thermoplastic, Red, 51 mm H x 16 mm W x 7 mm D Dimensions
Action Staggered Alternate Catalog Number XCSDMC590L01M8 Amperage Rating 100m A Application Packaging, Handling, Robotics, Machine Tools, Presses, Automotive Sector and Safety Detection Applications ARRA Compliant N Buy American Compliant N Catalog Number XCSDMC590L01M8 Color Red Connection M8,CONNECTOR ON FLYING LEAD Country of Origin FR Currency USD Enclosure THERMOPLASTIC PBT EU RoHS Indicator Y Gross Volume Per Pack 37.50 Gross Volume per Pack Metric 614.51 Gross Weight Per Pack 0.1000 lb Gross Weight per Pack Metric 44.00 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8536509065 Height 1.9000 in Height [Metric] 1.9000 cm Item Group 22411 Length 14.8000 in Length [Metric] 14.8000 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=858948&lang=en-us Number Of Poles 2 Operating Temperature -25-85 A°C Returnable Y Size 16 MM,51 MM,51 X 16 X 7 MM,7 MM Standard 10 GN 10-150 HZ)IEC 60068-2-6,30 GN 11 MS IEC 60068-2-27,BG-UL-CSA,IP67 IEC 60529,ISO 14119-UL 508-EN/IEC 60204-1-EN/IEC 60947-5-1-CSA C22.2 NO 14-EN/ISO 12100,CLASS II EN/IEC 61140 Sub Brand XCSDMC Substitute Product Catalog Number XZCP0941L2 Type CODED MAGNETIC SWITCH UNSPSC 39122213 UPC 11 78590157012 UPC 12 785901570127 Voltage Rating 24 VDC Warranty Description Contractual Warranty:18 months Width 15.5000 in Width [Metric] 15.5000 cm Stock Status NONSTOCK Brand Telemecanique Sensors Manufacturer Telemecanique Sensors Contact Configuration 1 NC + 1 NO Packaging, Handling, Robotics, Machine Tools, Presses, Automotive Sector and Safety Detection Applications PLASTIC
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Action | Staggered |
| Alternate Catalog Number | XCSDMC590L01M8 |
| Amperage Rating | 100m A |
| Application | Packaging, Handling, Robotics, Machine Tools, Presses, Automotive Sector and Safety Detection Applications |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | XCSDMC590L01M8 |
| Color | Red |
| Connection | M8,CONNECTOR ON FLYING LEAD |
| Country of Origin | FR |
| Currency | USD |
| Enclosure | THERMOPLASTIC PBT |
| EU RoHS Indicator | Y |
| Gross Volume Per Pack | 37.50 |
| Gross Volume per Pack Metric | 614.51 |
| Gross Weight Per Pack | 0.1000 lb |
| Gross Weight per Pack Metric | 44.00 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8536509065 |
| Height | 1.9000 in |
| Height [Metric] | 1.9000 cm |
| Item Group | 22411 |
| Length | 14.8000 in |
| Length [Metric] | 14.8000 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=858948&lang=en-us |
| Number Of Poles | 2 |
| Operating Temperature | -25-85 A°C |
| Returnable | Y |
| Size | 16 MM,51 MM,51 X 16 X 7 MM,7 MM |
| Standard | 10 GN 10-150 HZ)IEC 60068-2-6,30 GN 11 MS IEC 60068-2-27,BG-UL-CSA,IP67 IEC 60529,ISO 14119-UL 508-EN/IEC 60204-1-EN/IEC 60947-5-1-CSA C22.2 NO 14-EN/ISO 12100,CLASS II EN/IEC 61140 |
| Sub Brand | XCSDMC |
| Substitute Product Catalog Number | XZCP0941L2 |
| Type | CODED MAGNETIC SWITCH |
| UNSPSC | 39122213 |
| UPC 11 | 78590157012 |
| UPC 12 | 785901570127 |
| Voltage Rating | 24 VDC |
| Warranty Description | Contractual Warranty:18 months |
| Width | 15.5000 in |
| Width [Metric] | 15.5000 cm |
| Stock Status | NONSTOCK |
| Brand | Telemecanique Sensors |
| Manufacturer | Telemecanique Sensors |
| Contact Configuration | 1 NC + 1 NO |
| Packaging, Handling, Robotics, Machine Tools, Presses, Automotive Sector and Safety Detection Applications |
| PLASTIC |
