Square D™
Square D™ QOB3251021 Type QOB Miniature Circuit Breaker, 120/240 VAC/48 VDC, 25 A, 3 Poles, Shunt/Thermal Magnetic Trip
Custom_Product_Images_Illustration
Square D™
Square D™ QOB3251021 Type QOB Miniature Circuit Breaker, 120/240 VAC/48 VDC, 25 A, 3 Poles, Shunt/Thermal Magnetic Trip
SKU1016577
MFGR #QOB3251021
Your Cost: $531.37/ea
Square D QOB3251021 MINIATURE CIRCUIT BREAKER 240V 25A,10kA,240 Vac,25A,3-Phase,3P,Calibrated for use at 40 degrees C. See Data Bulletin 0100DB0101 for re-rating information.,Fiberglass filled thermoset molding material.,HACR rated,Miniature Circuit Breaker,Pressure Plate #14 to #8 AWG(Al/Cu),QO,Standard Bolt-On,UL Listed - CSA Certified
Square D QOB3251021 MINIATURE CIRCUIT BREAKER 240V 25A,10kA,240 Vac,25A,3-Phase,3P,Calibrated for use at 40 degrees C. See Data Bulletin 0100DB0101 for re-rating information.,Fiberglass filled thermoset molding material.,HACR rated,Miniature Circuit Breaker,Pressure Plate #14 to #8 AWG(Al/Cu),QO,Standard Bolt-On,UL Listed - CSA Certified
Alternate Catalog Number QOB3251021 Amperage Rating 25 A Application HACR rated ARRA Compliant N Brand Square D™ Buy American Compliant N Catalog Number QOB3251021 Connection Pressure Plate Connection Type Pressure Plate Country of Origin MX Currency USD Dimensions 2.91 in L x 3 in W x 3 in H EU RoHS Indicator Y Frequency Rating 50/60 Hz Gross Weight Per Pack 1210.0100 lb Gross Weight per Pack Metric 548.85 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200040 Height 7.9500 in Height [Metric] 7.9500 cm Interrupt Rating 10 kA Item Group 00015 Length 8.4330 in Length [Metric] 8.4330 cm Manufacturer Schneider Electric Material Fiberglass Filled Thermoset Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=401363&lang=en-us Mounting Type Bolt-On Number Of Poles 3 Operating Temperature 40 °C Phase 3 Returnable N Standard UL LISTED - CSA CERTIFIED Stock Status NONSTOCK Sub Brand QO Temperature Rating 104 °F Trip Type Shunt/Thermal Magnetic Type Type QOB Standard UNSPSC 39121603 UPC 11 78590185314 UPC 12 785901853145 Voltage Rating 240 VAC Warranty Description Contractual Warranty:18 months Width 7.5440 in Width [Metric] 7.5440 cm Wire Size 14 to 8 AWG HACR rated STANDARD BOLT-ON Designed for superior safety, quality and reliability Engineered with the quality and craftsmanship that have made Square D™ the preferred brand of electrician and homeowners First and only offer in the market to put the game changing Visi-Trip™ on all the circuit breakers for easy trip detection Saves space compact 3/4 in W design for small system footprint Faster installation fewer connections Frees gutter space no pigtails with the innovative plug-on neutral design Easier troubleshooting time saver diagnostics provide additional circuit information at the touch of a button
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | QOB3251021 |
| Amperage Rating | 25 A |
| Application | HACR rated |
| ARRA Compliant | N |
| Brand | Square D™ |
| Buy American Compliant | N |
| Catalog Number | QOB3251021 |
| Connection | Pressure Plate |
| Connection Type | Pressure Plate |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 2.91 in L x 3 in W x 3 in H |
| EU RoHS Indicator | Y |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 1210.0100 lb |
| Gross Weight per Pack Metric | 548.85 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200040 |
| Height | 7.9500 in |
| Height [Metric] | 7.9500 cm |
| Interrupt Rating | 10 kA |
| Item Group | 00015 |
| Length | 8.4330 in |
| Length [Metric] | 8.4330 cm |
| Manufacturer | Schneider Electric |
| Material | Fiberglass Filled Thermoset |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=401363&lang=en-us |
| Mounting Type | Bolt-On |
| Number Of Poles | 3 |
| Operating Temperature | 40 °C |
| Phase | 3 |
| Returnable | N |
| Standard | UL LISTED - CSA CERTIFIED |
| Stock Status | NONSTOCK |
| Sub Brand | QO |
| Temperature Rating | 104 °F |
| Trip Type | Shunt/Thermal Magnetic |
| Type | Type QOB Standard |
| UNSPSC | 39121603 |
| UPC 11 | 78590185314 |
| UPC 12 | 785901853145 |
| Voltage Rating | 240 VAC |
| Warranty Description | Contractual Warranty:18 months |
| Width | 7.5440 in |
| Width [Metric] | 7.5440 cm |
| Wire Size | 14 to 8 AWG |
| HACR rated |
| STANDARD BOLT-ON |
| Designed for superior safety, quality and reliability |
| Engineered with the quality and craftsmanship that have made Square D™ the preferred brand of electrician and homeowners |
| First and only offer in the market to put the game changing Visi-Trip™ on all the circuit breakers for easy trip detection |
| Saves space compact 3/4 in W design for small system footprint |
| Faster installation fewer connections |
| Frees gutter space no pigtails with the innovative plug-on neutral design |
| Easier troubleshooting time saver diagnostics provide additional circuit information at the touch of a button |
