Square D™ QOB1201044 Standard Miniature Circuit Breaker, 120/240 VAC, 20 A, 10 kA Interrupt, 1 Pole, Shunt Trip
Custom_Product_Images_Illustration
Square D™ QOB1201044 Standard Miniature Circuit Breaker, 120/240 VAC, 20 A, 10 kA Interrupt, 1 Pole, Shunt Trip
SKUPDW~11766174
MFGR #QOB1201044
Your Cost: $225.65/ea
List: Square D™ Miniature Circuit Breaker, Standard, 120/240 VAC, 20 A, 50/60 Hz Frequency, 10 kA Interrupt, Shunt Trip, 1 Pole, 14 to 8 AWG Al/Cu Wire, Bolt-On Mounting, 1.5 in W x 2.91 in D x 3 in H Dimensions
Square D™ Miniature Circuit Breaker, Standard, 120/240 VAC, 20 A, 50/60 Hz Frequency, 10 kA Interrupt, Shunt Trip, 1 Pole, 14 to 8 AWG Al/Cu Wire, Bolt-On Mounting, 1.5 in W x 2.91 in D x 3 in H Dimensions
Alternate Catalog Number QOB1201044 Application HACR and Switching Duty rated ARRA Compliant N Buy American Compliant N Catalog Number QOB1201044 Connection Pressure plate;AWG 14...AWG 8 copper or aluminium Country of Origin MX Currency USD EU RoHS Indicator Y Gross Weight Per Pack 1.3608 lb Gross Weight per Pack Metric 136.08 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200040 Height 3.8100 in Height [Metric] 3.8100 cm Item Group 00015 Length 8.3820 in Length [Metric] 8.3820 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=465332540&lang=en-us Number Of Poles 1 Returnable N Type Shunt trip 12/24 V AC/DC;Miniature circuit-breaker UNSPSC 39121603 Width 7.3660 in Width [Metric] 7.3660 cm Brand Square D™ Manufacturer Schneider Electric Amperage Rating 20 A Interrupt Rating 10 kA 120/240 V AC 50/60 Hz; 10 kA 120 V AC 50/60 Hz; 5 kA 48 V DC Voltage Rating 120/240 V AC;120 V AC HACR and Switching Duty rated
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Substitute Products
| Alternate Catalog Number | QOB1201044 |
| Application | HACR and Switching Duty rated |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | QOB1201044 |
| Connection | Pressure plate;AWG 14...AWG 8 copper or aluminium |
| Country of Origin | MX |
| Currency | USD |
| EU RoHS Indicator | Y |
| Gross Weight Per Pack | 1.3608 lb |
| Gross Weight per Pack Metric | 136.08 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200040 |
| Height | 3.8100 in |
| Height [Metric] | 3.8100 cm |
| Item Group | 00015 |
| Length | 8.3820 in |
| Length [Metric] | 8.3820 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=465332540&lang=en-us |
| Number Of Poles | 1 |
| Returnable | N |
| Type | Shunt trip 12/24 V AC/DC;Miniature circuit-breaker |
| UNSPSC | 39121603 |
| Width | 7.3660 in |
| Width [Metric] | 7.3660 cm |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 20 A |
| Interrupt Rating | 10 kA 120/240 V AC 50/60 Hz; 10 kA 120 V AC 50/60 Hz; 5 kA 48 V DC |
| Voltage Rating | 120/240 V AC;120 V AC |
| HACR and Switching Duty rated |
