Square D™
Square D™ PowerPact™ NJJF36225TW Molded Case Circuit Breaker With 3 LED Display, 600 VAC, 225 A, 100 kA at 240 VAC/65 kA at 480 VAC/25 kA at 600 VAC/20 kA at 250 VDC Interrupt, 3 Poles, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Square D™
Square D™ PowerPact™ NJJF36225TW Molded Case Circuit Breaker With 3 LED Display, 600 VAC, 225 A, 100 kA at 240 VAC/65 kA at 480 VAC/25 kA at 600 VAC/20 kA at 250 VDC Interrupt, 3 Poles, Thermal Magnetic Trip
SKUPDW~11431032
MFGR #NJJF36225TW
Price Not Available
Square D™ PowerPact™ Molded Case Circuit Breaker, 600 VAC, 225 A, 50/60 Hz, 100 kA at 240 VAC/65 kA at 480 VAC/25 kA at 600 VAC/20 kA at 250 VDC Interrupt, JJ Frame, Thermal Magnetic Trip, 225 A Trip, 3 Pole, 3, Toggle Actuator, Busbar/Line/Load Nut, 3/0 AWG to 350 kcmil Al/Cu Wire, NEMA AB1/IK07/IP40, DIN Rail/Flush Mount, 104 deg F, 4.1 in W x 3.4 in D x 7.5 in H
Square D™ PowerPact™ Molded Case Circuit Breaker, 600 VAC, 225 A, 50/60 Hz, 100 kA at 240 VAC/65 kA at 480 VAC/25 kA at 600 VAC/20 kA at 250 VDC Interrupt, JJ Frame, Thermal Magnetic Trip, 225 A Trip, 3 Pole, 3, Toggle Actuator, Busbar/Line/Load Nut, 3/0 AWG to 350 kcmil Al/Cu Wire, NEMA AB1/IK07/IP40, DIN Rail/Flush Mount, 104 deg F, 4.1 in W x 3.4 in D x 7.5 in H
Alternate Catalog Number NJJF36225TW Application Control Panel Applications ARRA Compliant N Buy American Compliant N Catalog Number NJJF36225TW Country of Origin US Currency USD EU RoHS Indicator Y Gross Weight Per Pack 5.0000 lb Gross Weight per Pack Metric 2.27 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 5.91 in Height [Metric] 15.0109 cm Item Group 01115 Length 8.86 in Length [Metric] 22.5039 cm Material Composition Declaration https://download.schneider-electric.com/files?p_Doc_Ref=NJJF36225TW_ROHS_DECLARATION&p_FileName=NJJF36225TW_ROHS_DECLARATION_US_en-US.pdf Returnable N Substitute Product Catalog Number PDC3JD20 UNSPSC 39121601 UPC 11 78590161489 UPC 12 785901614890 Warranty Description Contractual Warranty: 18 months Brand Square D™ Manufacturer Schneider Electric Control Panel Applications Common accessories and auxiliaries with other PowerPact™ frames Common accessories across the range of PowerPact™ molded case circuit breakers allow users to make late specification changes A wide range of field installable accessories allows customers to reduce inventory without sacrificing flexibility Broad offering of operating mechanisms and ratings specifically designed to be used as the main panel disconnect for control panel applications IEC style rotary operating handles Equipped with a unique terminal design that makes converting between busbar and lug options easy
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | NJJF36225TW |
| Application | Control Panel Applications |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | NJJF36225TW |
| Country of Origin | US |
| Currency | USD |
| EU RoHS Indicator | Y |
| Gross Weight Per Pack | 5.0000 lb |
| Gross Weight per Pack Metric | 2.27 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 5.91 in |
| Height [Metric] | 15.0109 cm |
| Item Group | 01115 |
| Length | 8.86 in |
| Length [Metric] | 22.5039 cm |
| Material Composition Declaration | https://download.schneider-electric.com/files?p_Doc_Ref=NJJF36225TW_ROHS_DECLARATION&p_FileName=NJJF36225TW_ROHS_DECLARATION_US_en-US.pdf |
| Returnable | N |
| Substitute Product Catalog Number | PDC3JD20 |
| UNSPSC | 39121601 |
| UPC 11 | 78590161489 |
| UPC 12 | 785901614890 |
| Warranty Description | Contractual Warranty: 18 months |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Control Panel Applications |
| Common accessories and auxiliaries with other PowerPact™ frames |
| Common accessories across the range of PowerPact™ molded case circuit breakers allow users to make late specification changes |
| A wide range of field installable accessories allows customers to reduce inventory without sacrificing flexibility |
| Broad offering of operating mechanisms and ratings specifically designed to be used as the main panel disconnect for control panel applications |
| IEC style rotary operating handles |
| Equipped with a unique terminal design that makes converting between busbar and lug options easy |
