Square D™
Square D™ PowerPact™ MGL26400 80% Rated Molded Case Circuit Breaker, 600 VAC, 400 A, 2 Poles
Custom_Product_Images_Illustration
Square D™
Square D™ PowerPact™ MGL26400 80% Rated Molded Case Circuit Breaker, 600 VAC, 400 A, 2 Poles
SKU417335
MFGR #MGL26400
Your Cost: $5,168.17/ea
List: Square D MGL26400 MOLDED CASE CIRCUIT BREAKER 600V 400A,12.80 in.,1ph,2P,400A,400A,40deg Celsius,50/60Hz,600 Vac,65kA240Vac - 35kA480Vac - 18kA600Vac,8.10 in.,8.30 in.,Ambient environment,Basic (ET1.0) Fixed Long-Time Adjustable Instantaneous Trip,Electronic,Electronic Trip Circuit Breaker,Lugs (ON and OFF ends),M-Frame,Powerpact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,Unit Mount,Various
Square D MGL26400 MOLDED CASE CIRCUIT BREAKER 600V 400A,12.80 in.,1ph,2P,400A,400A,40deg Celsius,50/60Hz,600 Vac,65kA240Vac - 35kA480Vac - 18kA600Vac,8.10 in.,8.30 in.,Ambient environment,Basic (ET1.0) Fixed Long-Time Adjustable Instantaneous Trip,Electronic,Electronic Trip Circuit Breaker,Lugs (ON and OFF ends),M-Frame,Powerpact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,Unit Mount,Various
Actuator ELECTRONIC Actuator Type Electronic Alternate Catalog Number MGL26400 Application PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION ARRA Compliant N Buy American Compliant N Catalog Number MGL26400 Connection LUGS (ON AND OFF ENDS) Connection Type Line/Load Lugs Country of Origin UKN Currency USD Dimensions 8.1 in L x 8.3 in W x 12.8 in H Enclosure Type NEMA AB1 Environmental Conditions AMBIENT ENVIRONMENT EU RoHS Indicator Y Frame M Frame Frequency Rating 50/60 Hz Gross Weight Per Pack 29.0000 lb Gross Weight per Pack Metric 12.70 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 12.74 in Height [Metric] 32.6600 cm Item Group 01205 Length 8.19 in Length [Metric] 21.0000 cm Material Various Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=430881&lang=en-us Mounting Type Unit Number Of Poles 2 Operating Temperature 40 °C Phase 1 pH Returnable Y Standard UL LISTED - CSA CERTIFIED - IEC RATED Standards UL 489 File No. E10027CE CertifiedCSA C22.2 File No. 5-02 File No. LR7551NMX J-266IEC 60947-2Federal Specification W-C-375BPROP65: Cancer and Reproductive Harm - www.P65Warnings.ca.gov Sub Brand POWERPACT Temperature Rating 104 °F Trip Range 800 to 4000 A Type 80% Rated UNSPSC 39121601 UPC 11 78590150756 UPC 12 785901507567 Warranty Description Contractual Warranty:18 months Width 7.98 in Width [Metric] 20.4600 cm Wire Size 3/0 AWG to 500 kcmil Al/Cu Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 400 A Interrupt Rating 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC Trip Type Electronic Basic ET 1.0 LI Voltage Rating 600 VAC PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION UNIT MOUNT True RMS sensing devices Provide means to manually disconnect power to the circuit Provide enhanced coordination by their adjustability Provide high interrupting ratings and withstand ratings
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator | ELECTRONIC |
| Actuator Type | Electronic |
| Alternate Catalog Number | MGL26400 |
| Application | PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | MGL26400 |
| Connection | LUGS (ON AND OFF ENDS) |
| Connection Type | Line/Load Lugs |
| Country of Origin | UKN |
| Currency | USD |
| Dimensions | 8.1 in L x 8.3 in W x 12.8 in H |
| Enclosure Type | NEMA AB1 |
| Environmental Conditions | AMBIENT ENVIRONMENT |
| EU RoHS Indicator | Y |
| Frame | M Frame |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 29.0000 lb |
| Gross Weight per Pack Metric | 12.70 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 12.74 in |
| Height [Metric] | 32.6600 cm |
| Item Group | 01205 |
| Length | 8.19 in |
| Length [Metric] | 21.0000 cm |
| Material | Various |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=430881&lang=en-us |
| Mounting Type | Unit |
| Number Of Poles | 2 |
| Operating Temperature | 40 °C |
| Phase | 1 pH |
| Returnable | Y |
| Standard | UL LISTED - CSA CERTIFIED - IEC RATED |
| Standards | UL 489 File No. E10027CE CertifiedCSA C22.2 File No. 5-02 File No. LR7551NMX J-266IEC 60947-2Federal Specification W-C-375BPROP65: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Sub Brand | POWERPACT |
| Temperature Rating | 104 °F |
| Trip Range | 800 to 4000 A |
| Type | 80% Rated |
| UNSPSC | 39121601 |
| UPC 11 | 78590150756 |
| UPC 12 | 785901507567 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 7.98 in |
| Width [Metric] | 20.4600 cm |
| Wire Size | 3/0 AWG to 500 kcmil Al/Cu |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 400 A |
| Interrupt Rating | 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC |
| Trip Type | Electronic Basic ET 1.0 LI |
| Voltage Rating | 600 VAC |
| PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| UNIT MOUNT |
| True RMS sensing devices |
| Provide means to manually disconnect power to the circuit |
| Provide enhanced coordination by their adjustability |
| Provide high interrupting ratings and withstand ratings |
