Square D™ PowerPact™ HJL26035 Type HJL Molded Case Circuit Breaker, 600 VAC/250 VDC, 35 A, 2 Poles
Molded Case Circuit Breakers
429236
MFG #: HJL26035
Square D™
1892.62000
/ ea
Square D HJL26035 MOLDED CASE CIRCUIT BREAKER 600V 35A,2-Pole,25 kA 600 V AC-100 kA 240 V AC-65 kA 480 V AC-20 kA 250 V DC,250 V DC-600 V AC,250 V DC-600 V AC,35 A,35 A,400 A,850 A,J,PowerPact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,circuit breaker,thermal-magnetic,unit mount
- Brochure URL - 11003_35R1PTDFMVK20N68.pdf(Brochure URL)
- Catalog URL - Square_D_HDA260151_Brochure.pdf(Catalog URL)
- Seller Home Page URL - us(Seller Home Page URL)
- Install Instructions URL - Square_D_HDA260151_Instruction_Sheet.pdf(Install Instructions URL)
- Service Manual URL - 11003_T6POCH3LUD9I1KN0.pdf(Service Manual URL)
- Computer~Aided [CAD|BIM] Model URL(Computer~Aided [CAD|BIM] Model URL)
- User Manual URL - 11003_E9IAMWVOKTCDJUNZ.pdf(User Manual URL)
- Spec Sheet URL - 11003_LPW87M6KYA3UNV0O.pdf(Spec Sheet URL)
- Tech Bulletin URL - 11003_9UXPLAQ71E6F2BGM.pdf(Tech Bulletin URL)
- Video - https://www.youtube.com/embed/1PjFQgO_-Ik(Video)
- Tech Drawing URL - 11003_JPQB3S7VWZE5U4X8.zip(Tech Drawing URL)
- Applications
- Features
| PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| UNIT MOUNT |
| Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields |
| Flexible and simple offer, with proven performance |
| Direct access to energy metering and energy efficiency |
| 65 kA at 480 VAC, 25 kA at 600 VAC, 100 kA at 240 VAC, 20 kA at 250 VDC interrupt rating |
