Square D™ PowerPact™ HGL36150LV Molded Case Circuit Breaker, 600 VAC, 150 A, 18 kA Interrupt, 3 Poles, Thermal Magnetic Trip
Square D™ PowerPact™ HGL36150LV Molded Case Circuit Breaker, 600 VAC, 150 A, 18 kA Interrupt, 3 Poles, Thermal Magnetic Trip
SKUPDW~11720706
MFGR #HGL36150LV
Your Cost: $2,561.51/ea
List: Square D™ PowerPact™ Molded Case Circuit Breaker, 600 VAC, 150 A, 50/60 Hz Frequency, 18 kA Interrupt, H Frame, Thermal Magnetic Trip, 900 to 1700 A Trip, 3 Poles, Lug Line/Load Connection, 14 to 3/0 AWG Al/Cu Wire, NEMA AB1 Enclosure, Backplate/DIN Rail/Flush Mounting, 104 deg F, 4.12 in W x 4.36 in D x 6.4 in H Dimensions
Square D™ PowerPact™ Molded Case Circuit Breaker, 600 VAC, 150 A, 50/60 Hz Frequency, 18 kA Interrupt, H Frame, Thermal Magnetic Trip, 900 to 1700 A Trip, 3 Poles, Lug Line/Load Connection, 14 to 3/0 AWG Al/Cu Wire, NEMA AB1 Enclosure, Backplate/DIN Rail/Flush Mounting, 104 deg F, 4.12 in W x 4.36 in D x 6.4 in H Dimensions
Alternate Catalog Number HGL36150LV Application Construction, Commercial Buildings, Oil and Gas, Control Equipment Panels, Marine, Industrial Buildings, Water Wastewater, OEM Commercial, Healthcare Facilities, Data Centers, Educational Campuses and Industrial Markets Applications ARRA Compliant N Buy American Compliant N Catalog Number HGL36150LV Connection Lugs line;lugs load; AWG 14...AWG 3/0 aluminium/copper terminal Country of Origin US Currency USD EU RoHS Indicator Y Gross Weight Per Pack 5.0000 lb Gross Weight per Pack Metric 2.27 Gross Weight UOM Metric kg Height 6.36 in Height [Metric] 16.3000 cm Item Group 01115 Length 4.33 in Length [Metric] 11.1000 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=423259438&lang=en-us Number Of Poles 3 Returnable N Substitute Product Catalog Number S29386 Type Circuit Breaker UNSPSC 39121601 UPC 11 78590155569 UPC 12 785901555698 Upsell Product Catalog Number S29450 Width 4.10 in Width [Metric] 10.5000 cm Brand Square D™ Manufacturer Schneider Electric Trip Type THERMAL-MAGNETIC Construction, Commercial Buildings, Oil and Gas, Control Equipment Panels, Marine, Industrial Buildings, Water Wastewater, OEM Commercial, Healthcare Facilities, Data Centers, Educational Campuses and Industrial Markets Applications Control wire OFF end;Modbus;Ethernet Common mounting holes, handle locations and trim dimensions across the range allow design standardization using PowerPact™ H and J-frame circuit breakers Common accessories across the range of PowerPact™ Molded Case circuit breakers allow users to make late specification changes A wide range of field installable accessories allows customers to reduce inventory without sacrificing flexibility Broad offering of operating mechanisms and ratings specifically designed to be used as the main panel disconnect for control panel applications IEC style rotary operating handles NEMA 9421 door mounted rotary operating mechanism NEMA 9422 flange mounted operating mechanism in two styles - bracket mounted or cable operated Equipped with a unique snap-in terminal design that makes converting between busbar and lug options easy Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields Flexible and simple offer, with proven performance Flexible and simple offer, with proven performance Direct access to energy metering and energy efficiency thanks to the Micrologic control units
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | HGL36150LV |
| Application | Construction, Commercial Buildings, Oil and Gas, Control Equipment Panels, Marine, Industrial Buildings, Water Wastewater, OEM Commercial, Healthcare Facilities, Data Centers, Educational Campuses and Industrial Markets Applications |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | HGL36150LV |
| Connection | Lugs line;lugs load; AWG 14...AWG 3/0 aluminium/copper terminal |
| Country of Origin | US |
| Currency | USD |
| EU RoHS Indicator | Y |
| Gross Weight Per Pack | 5.0000 lb |
| Gross Weight per Pack Metric | 2.27 |
| Gross Weight UOM Metric | kg |
| Height | 6.36 in |
| Height [Metric] | 16.3000 cm |
| Item Group | 01115 |
| Length | 4.33 in |
| Length [Metric] | 11.1000 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=423259438&lang=en-us |
| Number Of Poles | 3 |
| Returnable | N |
| Substitute Product Catalog Number | S29386 |
| Type | Circuit Breaker |
| UNSPSC | 39121601 |
| UPC 11 | 78590155569 |
| UPC 12 | 785901555698 |
| Upsell Product Catalog Number | S29450 |
| Width | 4.10 in |
| Width [Metric] | 10.5000 cm |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Trip Type | THERMAL-MAGNETIC |
| Construction, Commercial Buildings, Oil and Gas, Control Equipment Panels, Marine, Industrial Buildings, Water Wastewater, OEM Commercial, Healthcare Facilities, Data Centers, Educational Campuses and Industrial Markets Applications |
| Control wire OFF end;Modbus;Ethernet |
| Common mounting holes, handle locations and trim dimensions across the range allow design standardization using PowerPact™ H and J-frame circuit breakers |
| Common accessories across the range of PowerPact™ Molded Case circuit breakers allow users to make late specification changes |
| A wide range of field installable accessories allows customers to reduce inventory without sacrificing flexibility |
| Broad offering of operating mechanisms and ratings specifically designed to be used as the main panel disconnect for control panel applications |
| IEC style rotary operating handles |
| NEMA 9421 door mounted rotary operating mechanism |
| NEMA 9422 flange mounted operating mechanism in two styles - bracket mounted or cable operated |
| Equipped with a unique snap-in terminal design that makes converting between busbar and lug options easy |
| Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields |
| Flexible and simple offer, with proven performance |
| Flexible and simple offer, with proven performance |
| Direct access to energy metering and energy efficiency thanks to the Micrologic control units |
