Square D™ PowerPact™ HGL26080 Type HGL Molded Case Circuit Breaker, 600 VAC/250 VDC, 80 A, 2 Poles
Custom_Product_Images_Illustration
Square D™ PowerPact™ HGL26080 Type HGL Molded Case Circuit Breaker, 600 VAC/250 VDC, 80 A, 2 Poles
SKU429219
MFGR #HGL26080
Your Cost: $1,298.11/ea
List: Square D HGL26080 MOLDED CASE CIRCUIT BREAKER 600V 80A,-25deg.C (-13deg.F) and +70deg.C (158deg. F).,2-Poles,250 V DC600 V AC,250 V DC600 V AC 20 kA 250 V DC65 kA 240 V AC35 kA 480 V AC18 kA 600 V AC,3.440 in,4.120 in,50/60 Hz,6.4 in,80 A,800 A 1450 A 80 A,95 At 55 deg C Relative Humidity,H- Frame,Line/Load Lug Terminal,Molded Case Circuit Breaker,PowerPact,Toggle,UL Listed, CSA Approved, IEC Rated,thermal-magnetic,unit mount
Square D HGL26080 MOLDED CASE CIRCUIT BREAKER 600V 80A,-25deg.C (-13deg.F) and +70deg.C (158deg. F).,2-Poles,250 V DC600 V AC,250 V DC600 V AC 20 kA 250 V DC65 kA 240 V AC35 kA 480 V AC18 kA 600 V AC,3.440 in,4.120 in,50/60 Hz,6.4 in,80 A,800 A 1450 A 80 A,95 At 55 deg C Relative Humidity,H- Frame,Line/Load Lug Terminal,Molded Case Circuit Breaker,PowerPact,Toggle,UL Listed, CSA Approved, IEC Rated,thermal-magnetic,unit mount
Actuator Toggle Actuator Type Toggle Alternate Catalog Number HGL26080 ARRA Compliant N Buy American Compliant N Catalog Number HGL26080 Connection LINE/LOAD LUG TERMINAL Connection Type Line/Load Lugs Country of Origin US Currency USD Dimensions 3.44 in L x 4.12 in W x 6.4 in H Enclosure Type NEMA AB1 Environmental Conditions 95 AT 55 DEG C RELATIVE HUMIDITY EU RoHS Indicator Y Frame H Frequency Rating 50/60 Hz Gross Weight Per Pack 3.0400 lb Gross Weight per Pack Metric 1.38 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 13.0180 in Height [Metric] 13.0180 cm Item Group 01115 Length 21.4330 in Length [Metric] 21.4330 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=422651&lang=en-us Mounting Type Unit Number Of Poles 2 Operating Temperature -13 to 158F (-25 to 70C) °C Phase 1 pH Returnable Y Standard UL LISTED, CSA APPROVED, IEC RATED Sub Brand POWERPACT Temperature Rating -13 to 158 °F Trip Range 800 to 1450 A Type Type HGL UNSPSC 39121601 UPC 11 78590143387 UPC 12 785901433873 Warranty Description Contractual Warranty:18 months Width 18.4150 in Width [Metric] 18.4150 cm Wire Size 14 to 3/0 AWG Al/Cu Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 80 A Interrupt Rating 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC/20 kA at 250 VDC/500 VDC Trip Type Thermal Magnetic Voltage Rating 600 VAC/250 VDC UNIT MOUNT Easy to install, extremely versatile, a wide variety of terminal Flexible and simple offer, with proven performance Direct access to energy metering and energy efficiency
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Actuator | Toggle |
| Actuator Type | Toggle |
| Alternate Catalog Number | HGL26080 |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | HGL26080 |
| Connection | LINE/LOAD LUG TERMINAL |
| Connection Type | Line/Load Lugs |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 3.44 in L x 4.12 in W x 6.4 in H |
| Enclosure Type | NEMA AB1 |
| Environmental Conditions | 95 AT 55 DEG C RELATIVE HUMIDITY |
| EU RoHS Indicator | Y |
| Frame | H |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 3.0400 lb |
| Gross Weight per Pack Metric | 1.38 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 13.0180 in |
| Height [Metric] | 13.0180 cm |
| Item Group | 01115 |
| Length | 21.4330 in |
| Length [Metric] | 21.4330 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=422651&lang=en-us |
| Mounting Type | Unit |
| Number Of Poles | 2 |
| Operating Temperature | -13 to 158F (-25 to 70C) °C |
| Phase | 1 pH |
| Returnable | Y |
| Standard | UL LISTED, CSA APPROVED, IEC RATED |
| Sub Brand | POWERPACT |
| Temperature Rating | -13 to 158 °F |
| Trip Range | 800 to 1450 A |
| Type | Type HGL |
| UNSPSC | 39121601 |
| UPC 11 | 78590143387 |
| UPC 12 | 785901433873 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 18.4150 in |
| Width [Metric] | 18.4150 cm |
| Wire Size | 14 to 3/0 AWG Al/Cu |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 80 A |
| Interrupt Rating | 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC/20 kA at 250 VDC/500 VDC |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 600 VAC/250 VDC |
| UNIT MOUNT |
| Easy to install, extremely versatile, a wide variety of terminal |
| Flexible and simple offer, with proven performance |
| Direct access to energy metering and energy efficiency |
