Square D™ MJL36400LW Molded Case Circuit Breaker, 600 VAC, 400 A, 100 kA at 240 VAC, 65 kA at 480 VAC, 25 kA at 600 VAC Interrupt, 3 Poles, Electronic Basic ET 1.0 LI/Non-Interchangeable Trip
Custom_Product_Images_Illustration
Square D™ MJL36400LW Molded Case Circuit Breaker, 600 VAC, 400 A, 100 kA at 240 VAC, 65 kA at 480 VAC, 25 kA at 600 VAC Interrupt, 3 Poles, Electronic Basic ET 1.0 LI/Non-Interchangeable Trip
SKUPDW~9920246
MFGR #MJL36400LW
Your Cost: $6,713.08/ea
List: Square D™ PowerPact™ Molded Case Circuit Breaker, 600 VAC, 400 A, 50/60 Hz, 100 kA at 240 VAC, 65 kA at 480 VAC, 25 kA at 600 VAC Interrupt, M Frame, Electronic Basic ET 1.0 LI/Non-Interchangeable Trip, 400 A Trip, 3 Pole, 3, Manual Actuator, Line/Load Lug, 3/0 AWG to 500 kcmil Al/Cu Wire, Unit Mount, -22 to 158 deg F, 12.86 in H x 8.27 in W x 8.07 in D
Square D™ PowerPact™ Molded Case Circuit Breaker, 600 VAC, 400 A, 50/60 Hz, 100 kA at 240 VAC, 65 kA at 480 VAC, 25 kA at 600 VAC Interrupt, M Frame, Electronic Basic ET 1.0 LI/Non-Interchangeable Trip, 400 A Trip, 3 Pole, 3, Manual Actuator, Line/Load Lug, 3/0 AWG to 500 kcmil Al/Cu Wire, Unit Mount, -22 to 158 deg F, 12.86 in H x 8.27 in W x 8.07 in D
Alternate Catalog Number MJL36400LW Application Distribution ARRA Compliant N Buy American Compliant N Catalog Number MJL36400LW Connection AWG 3/0...500 KCMIL ALUMINIUM/COPPER)3,LUGS LOAD-LUGS LINE Country of Origin US Currency USD EU RoHS Indicator Y Frame J Gross Weight Per Pack 30.0000 lb Gross Weight per Pack Metric 13.61 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 12.86 in Item Group 01205 Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=268668554&lang=en-us Number Of Poles 3 Returnable Y Standard IEC-UL LISTED-CSA Trip Range 400 A,400 A Type CIRCUIT BREAKER,CONTROL CABLE ON AND OFF END UNSPSC 39121601 UPC 11 78590195097 UPC 12 785901950974 Warranty Description Contractual Warranty:18 months Width 8.27 in Brand Square D™ Manufacturer Schneider Electric Amperage Rating 400 A Interrupt Rating 100 KA 240 V AC-65 KA 480 V AC-25 KA 600 V AC,600 V AC Trip Type ELECTRONIC, BASIC, ET 1.0, LI Voltage Rating 600 VAC Distribution UNIT MOUNT
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | MJL36400LW |
| Application | Distribution |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | MJL36400LW |
| Connection | AWG 3/0...500 KCMIL ALUMINIUM/COPPER)3,LUGS LOAD-LUGS LINE |
| Country of Origin | US |
| Currency | USD |
| EU RoHS Indicator | Y |
| Frame | J |
| Gross Weight Per Pack | 30.0000 lb |
| Gross Weight per Pack Metric | 13.61 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 12.86 in |
| Item Group | 01205 |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=268668554&lang=en-us |
| Number Of Poles | 3 |
| Returnable | Y |
| Standard | IEC-UL LISTED-CSA |
| Trip Range | 400 A,400 A |
| Type | CIRCUIT BREAKER,CONTROL CABLE ON AND OFF END |
| UNSPSC | 39121601 |
| UPC 11 | 78590195097 |
| UPC 12 | 785901950974 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 8.27 in |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 400 A |
| Interrupt Rating | 100 KA 240 V AC-65 KA 480 V AC-25 KA 600 V AC,600 V AC |
| Trip Type | ELECTRONIC, BASIC, ET 1.0, LI |
| Voltage Rating | 600 VAC |
| Distribution |
| UNIT MOUNT |
