Square D™
Square D™ MGL36400SA Molded Case Circuit Breaker, 600 VAC, 400 A, 65 kA at 240 VAC, 35 kA at 480 VAC, 18 kA at 600 VAC Interrupt, 3 Poles, Electronic Basic ET 1.0 LI/Non-Interchangeable Trip
Custom_Product_Images_Illustration
Square D™
Square D™ MGL36400SA Molded Case Circuit Breaker, 600 VAC, 400 A, 65 kA at 240 VAC, 35 kA at 480 VAC, 18 kA at 600 VAC Interrupt, 3 Poles, Electronic Basic ET 1.0 LI/Non-Interchangeable Trip
SKUPDW~11744401
MFGR #MGL36400SA
Your Cost: $5,867.06/ea
List: Square D™ PowerPact™ Molded Case Circuit Breaker, 600 VAC, 400 A, 50/60 Hz, 65 kA at 240 VAC, 35 kA at 480 VAC, 18 kA at 600 VAC Interrupt, M Frame, Electronic Basic ET 1.0 LI/Non-Interchangeable Trip, 400 A Trip, 3 Pole, 3, Manual Actuator, Line/Load Lug, 3/0 AWG to 500 kcmil Al/Cu Wire, Unit Mount, -22 to 158 deg F, 12.86 in H x 8.27 in W x 8.07 in D
Square D™ PowerPact™ Molded Case Circuit Breaker, 600 VAC, 400 A, 50/60 Hz, 65 kA at 240 VAC, 35 kA at 480 VAC, 18 kA at 600 VAC Interrupt, M Frame, Electronic Basic ET 1.0 LI/Non-Interchangeable Trip, 400 A Trip, 3 Pole, 3, Manual Actuator, Line/Load Lug, 3/0 AWG to 500 kcmil Al/Cu Wire, Unit Mount, -22 to 158 deg F, 12.86 in H x 8.27 in W x 8.07 in D
Actuator Type Manual Alternate Catalog Number MGL36400SA Application Distribution ARRA Compliant N Buy American Compliant N Catalog Number MGL36400SA Connection Lugs load;lugs line; 3 x AWG 3/0...3 x 500 kcmil aluminium/copper Connection Type Line/Load Lug Country of Origin US Currency USD Dimensions 12.86 in H x 8.27 in W x 8.07 in D EU RoHS Indicator Y Frame M Frequency Rating 50/60 Gross Weight Per Pack 28.9900 lb Gross Weight per Pack Metric 13.15 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 9.8425 in Height [Metric] 25.4000 cm Item Group 01205 Length 17.7165 in Length [Metric] 45.2450 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=268668374&lang=en-us Mounting Type Unit Number Of Poles 3 Phase 3 Returnable Y Standard IEC-UL LISTED-CSA Temperature Rating -22 to 158 Trip Range 400 Type CIRCUIT BREAKER UNSPSC 39121601 UPC 11 78590194412 UPC 12 785901944126 Warranty Description Contractual Warranty:18 months Width 11.8110 in Width [Metric] 29.8450 cm Wire Size 3/0 AWG to 500 kcmil Al/Cu Brand Square D™ Manufacturer Schneider Electric Amperage Rating 400 A Interrupt Rating 65 kA at 240 VAC, 35 kA at 480 VAC, 18 kA at 600 VAC Trip Type Electronic Basic ET 1.0 LI/Non-Interchangeable Voltage Rating 600 VAC Distribution Shunt trip 110...130 V AC/DC
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator Type | Manual |
| Alternate Catalog Number | MGL36400SA |
| Application | Distribution |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | MGL36400SA |
| Connection | Lugs load;lugs line; 3 x AWG 3/0...3 x 500 kcmil aluminium/copper |
| Connection Type | Line/Load Lug |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 12.86 in H x 8.27 in W x 8.07 in D |
| EU RoHS Indicator | Y |
| Frame | M |
| Frequency Rating | 50/60 |
| Gross Weight Per Pack | 28.9900 lb |
| Gross Weight per Pack Metric | 13.15 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 9.8425 in |
| Height [Metric] | 25.4000 cm |
| Item Group | 01205 |
| Length | 17.7165 in |
| Length [Metric] | 45.2450 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=268668374&lang=en-us |
| Mounting Type | Unit |
| Number Of Poles | 3 |
| Phase | 3 |
| Returnable | Y |
| Standard | IEC-UL LISTED-CSA |
| Temperature Rating | -22 to 158 |
| Trip Range | 400 |
| Type | CIRCUIT BREAKER |
| UNSPSC | 39121601 |
| UPC 11 | 78590194412 |
| UPC 12 | 785901944126 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 11.8110 in |
| Width [Metric] | 29.8450 cm |
| Wire Size | 3/0 AWG to 500 kcmil Al/Cu |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 400 A |
| Interrupt Rating | 65 kA at 240 VAC, 35 kA at 480 VAC, 18 kA at 600 VAC |
| Trip Type | Electronic Basic ET 1.0 LI/Non-Interchangeable |
| Voltage Rating | 600 VAC |
| Distribution |
| Shunt trip 110...130 V AC/DC |
