Square D™
Square D™ JJL36150T Molded Case Circuit Breaker, 600 VAC, 150 A, 100 kA at 240 VAC/65 kA at 480 VAC/25 kA at 600 VAC/20 kA at 250 VDC Interrupt, 3 Poles, Thermal/Magnetic Trip
Custom_Product_Images_Illustration
Square D™
Square D™ JJL36150T Molded Case Circuit Breaker, 600 VAC, 150 A, 100 kA at 240 VAC/65 kA at 480 VAC/25 kA at 600 VAC/20 kA at 250 VDC Interrupt, 3 Poles, Thermal/Magnetic Trip
SKUPDW~11730058
MFGR #JJL36150T
Your Cost: $3,810.00/ea
List: Schneider Electric PowerPact™ Molded Case Circuit Breaker, 600 VAC, 150 A, 50/60 Hz Frequency, 100 kA at 240 VAC/65 kA at 480 VAC/25 kA at 600 VAC/20 kA at 250 VDC Interrupt, J Frame Frame, Thermal/Magnetic Trip, 875 to 1750 A Trip, 3 Pole, 3 ph, Line/Load Lug Connection, 4 to 4/0 AWG Wire, NEMA AB1 Enclosure, Surface Mounting, 104 deg F, 6.4 in H x 4.12 in W x 4.36 in D Dimensions
Schneider Electric PowerPact™ Molded Case Circuit Breaker, 600 VAC, 150 A, 50/60 Hz Frequency, 100 kA at 240 VAC/65 kA at 480 VAC/25 kA at 600 VAC/20 kA at 250 VDC Interrupt, J Frame Frame, Thermal/Magnetic Trip, 875 to 1750 A Trip, 3 Pole, 3 ph, Line/Load Lug Connection, 4 to 4/0 AWG Wire, NEMA AB1 Enclosure, Surface Mounting, 104 deg F, 6.4 in H x 4.12 in W x 4.36 in D Dimensions
Alternate Catalog Number JJL36150T Application Distribution ARRA Compliant N Buy American Compliant N Catalog Number JJL36150T Connection Lugs line;lugs load; AWG 4...AWG 4/0 aluminium/copper terminal Connection Type Line/Load Lug Country of Origin US Currency USD Dimensions 6.4 in H x 4.12 in W x 4.36 in D Enclosure Type NEMA AB1 EU RoHS Indicator Y Frame J Frame Frequency Rating 50/60 Gross Weight Per Pack 0.0204 lb Gross Weight per Pack Metric 2.04 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 13.0180 in Height [Metric] 13.0180 cm Item Group 01115 Length 21.4330 in Length [Metric] 21.4330 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=426043&lang=en-us Mounting Type Surface Number Of Poles 3 Operating Temperature 40 A°C Phase 3 Returnable Y Standard UL LISTED-CSA-CE-IEC-CCC Temperature Rating 104 Trip Range 875 to 1750 Type CIRCUIT BREAKER UNSPSC 39121601 UPC 11 78590176042 UPC 12 785901760429 Warranty Description Contractual Warranty:18 months Width 18.4150 in Width [Metric] 18.4150 cm Wire Size 4 to 4/0 Brand Square D™ Manufacturer Schneider Electric Amperage Rating 150 A Interrupt Rating 100 kA at 240 VAC/65 kA at 480 VAC/25 kA at 600 VAC/20 kA at 250 VDC Trip Type Thermal Magnetic Voltage Rating 600 Distribution Modbus;Ethernet
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | JJL36150T |
| Application | Distribution |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | JJL36150T |
| Connection | Lugs line;lugs load; AWG 4...AWG 4/0 aluminium/copper terminal |
| Connection Type | Line/Load Lug |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 6.4 in H x 4.12 in W x 4.36 in D |
| Enclosure Type | NEMA AB1 |
| EU RoHS Indicator | Y |
| Frame | J Frame |
| Frequency Rating | 50/60 |
| Gross Weight Per Pack | 0.0204 lb |
| Gross Weight per Pack Metric | 2.04 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 13.0180 in |
| Height [Metric] | 13.0180 cm |
| Item Group | 01115 |
| Length | 21.4330 in |
| Length [Metric] | 21.4330 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=426043&lang=en-us |
| Mounting Type | Surface |
| Number Of Poles | 3 |
| Operating Temperature | 40 A°C |
| Phase | 3 |
| Returnable | Y |
| Standard | UL LISTED-CSA-CE-IEC-CCC |
| Temperature Rating | 104 |
| Trip Range | 875 to 1750 |
| Type | CIRCUIT BREAKER |
| UNSPSC | 39121601 |
| UPC 11 | 78590176042 |
| UPC 12 | 785901760429 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 18.4150 in |
| Width [Metric] | 18.4150 cm |
| Wire Size | 4 to 4/0 |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 150 A |
| Interrupt Rating | 100 kA at 240 VAC/65 kA at 480 VAC/25 kA at 600 VAC/20 kA at 250 VDC |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 600 |
| Distribution |
| Modbus;Ethernet |
