Square D™ I-Line™ PowerPact™ JLA262005 Molded Case Circuit Breaker, 600 VAC, 200 A, 2 Poles, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Square D™ I-Line™ PowerPact™ JLA262005 Molded Case Circuit Breaker, 600 VAC, 200 A, 2 Poles, Thermal Magnetic Trip
SKUPDW~6404974
MFGR #JLA262005
Price Not Available
The PowerPact™ H, J and L-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. H and J-frame circuit breakers are available with either thermal-magnetic or Micrologic™ electronic trip units. L-frame circuit breakers are available with Micrologic™ electronic trip units only. H and J-frame circuit breakers with thermal-magnetic trip units contain individual thermal (overload) and instantaneous (short circuit) sensing elements in each pole. The amperage ratings of the thermal trip elements are calibrated at 104 deg F free air ambient temperature. Per the National Electric Code® (NEC®) and the Canadian Electrical Code®, standard circuit breakers may only be applied continuously at up to 80% of their rating. Circuit breakers rated for 100% operation are available but require specially-designed enclosures and 194 deg F rated wire.
The PowerPact™ H, J and L-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. H and J-frame circuit breakers are available with either thermal-magnetic or Micrologic™ electronic trip units. L-frame circuit breakers are available with Micrologic™ electronic trip units only. H and J-frame circuit breakers with thermal-magnetic trip units contain individual thermal (overload) and instantaneous (short circuit) sensing elements in each pole. The amperage ratings of the thermal trip elements are calibrated at 104 deg F free air ambient temperature. Per the National Electric Code® (NEC®) and the Canadian Electrical Code®, standard circuit breakers may only be applied continuously at up to 80% of their rating. Circuit breakers rated for 100% operation are available but require specially-designed enclosures and 194 deg F rated wire.
Actuator Type Toggle Alternate Catalog Number JLA262005 ARRA Compliant N Buy American Compliant N Catalog Number JLA262005 Connection AWG 3/0...350 KCMIL ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD Connection Type Line/Load Lug Country of Origin US Currency USD Dimensions 6.4 in H x 2.74 in W x 4.36 in D EU RoHS Indicator Y Frame J Frame Frequency Rating 50/60 Hz Gross Weight Per Pack 0.0204 lb Gross Weight per Pack Metric 2.04 Gross Weight UOM Metric kg Height 29.2000 in Height [Metric] 29.2000 cm Item Group 01122 Length 14.9000 in Length [Metric] 14.9000 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=426271&lang=en-us Number Of Poles 2 Operating Temperature 40 °C Phase 1 pH Returnable N Standard UL LISTED-CSA-IEC-CE-CCC Temperature Rating 104 °F Trip Range 1000 to 2000 A Type 80% Rated UNSPSC 39121601 UPC 11 78590193933 UPC 12 785901939337 Warranty Description Contractual Warranty:18 months Width 11.4000 in Width [Metric] 11.4000 cm Wire Size 3/0 AWG to 350 kcmil Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 200 A Interrupt Rating 125 kA at 240 VAC/100 kA at 480 VAC/50 kA at 600 VAC/20 kA at 250 VDC/50 kA at 500 VDC Trip Type Thermal Magnetic Voltage Rating 600 VAC I-LINE Rated current from 70 to 250 A Breaking capacity from 18 to 65 kA at 480 VAC Common accessories and auxiliaries with other PowerPact™ frames 20 kA at 250 VDC, 125 kA at 240 VAC, 100 kA at 480 VAC, 50 kA at 600 VAC, 50 kA at 500 VDC interrupt rating
