Square D™ I-Line™ PowerPact™ JJA261754 Molded Case Circuit Breaker, 600 VAC, 175 A, 2 Poles, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Square D™ I-Line™ PowerPact™ JJA261754 Molded Case Circuit Breaker, 600 VAC, 175 A, 2 Poles, Thermal Magnetic Trip
SKUPDW~6404910
MFGR #JJA261754
Price Not Available
The PowerPact™ H, J and L-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. H and J-frame circuit breakers are available with either thermal-magnetic or Micrologic™ electronic trip units. L-frame circuit breakers are available with Micrologic™ electronic trip units only. H and J-frame circuit breakers with thermal-magnetic trip units contain individual thermal (overload) and instantaneous (short circuit) sensing elements in each pole. The amperage ratings of the thermal trip elements are calibrated at 104 deg F free air ambient temperature. Per the National Electric Code® (NEC®) and the Canadian Electrical Code®, standard circuit breakers may only be applied continuously at up to 80% of their rating. Circuit breakers rated for 100% operation are available but require specially-designed enclosures and 194 deg F rated wire.
The PowerPact™ H, J and L-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. H and J-frame circuit breakers are available with either thermal-magnetic or Micrologic™ electronic trip units. L-frame circuit breakers are available with Micrologic™ electronic trip units only. H and J-frame circuit breakers with thermal-magnetic trip units contain individual thermal (overload) and instantaneous (short circuit) sensing elements in each pole. The amperage ratings of the thermal trip elements are calibrated at 104 deg F free air ambient temperature. Per the National Electric Code® (NEC®) and the Canadian Electrical Code®, standard circuit breakers may only be applied continuously at up to 80% of their rating. Circuit breakers rated for 100% operation are available but require specially-designed enclosures and 194 deg F rated wire.
Actuator Type Toggle Catalog Number JJA261754 Connection Type Line/Load Lug Country of Origin US Currency USD Dimensions 6.4 in H x 2.74 in W x 4.36 in D Frame J Frame Frequency Rating 50/60 Hz Gross Weight Per Pack 0.0204 lb Gross Weight per Pack Metric 2.04 Gross Weight UOM Metric kg Height 13.6530 in Item Group 01117 Length 37.1480 in Mounting Type Surface Number Of Poles 2 Phase 1 pH Returnable Y Standards ARRA CompliantBuy American Act CompliantRoHS CompliantUL 489 File No. E10027CSA C22.2 No. 5-02 File No. LR40970CCC/CE MarkedNMX J-266Federal Specification W-C-375B/GENIEC 60947-2NEMA AB1eccn: EAR99 Temperature Rating 104 °F Trip Range 875 to 1750 A Type Type JJA UNSPSC 39121616 UPC 11 78590193917 UPC 12 785901939177 Width 20.6380 in Wire Size 4 to 4/0 AWG Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 175 A Interrupt Rating 100 kA at 240 VAC/65 kA at 480 VAC/25 kA at 600 VAC/20 kA at 250 VDC Trip Type Thermal Magnetic Voltage Rating 600 VAC/250 VDC I-LINE Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields Flexible and simple offer, with proven performance Direct access to energy metering and energy efficiency 20 kA at 250 VDC, 100 kA at 240 VAC, 65 kA at 480 VAC, 25 kA at 600 VAC interrupt rating
