Square D™ I-Line™ PowerPact™ JGA262254 Type JGA Molded Case Circuit Breaker, 600 VAC/500 VDC, 225 A, 2 Poles
Custom_Product_Images_Illustration
Square D™ I-Line™ PowerPact™ JGA262254 Type JGA Molded Case Circuit Breaker, 600 VAC/500 VDC, 225 A, 2 Poles
SKUPDW~6404859
MFGR #JGA262254
Price Not Available
Square D™ I-Line™ PowerPact™ Molded Case Circuit Breaker, Type JGA, 600 VAC/500 VDC, 225 A, 50/60 Hz, 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC/20 kA at 250 VDC Interrupt, J Frame, Thermal Magnetic Trip, 1125 to 2250 A Trip, 2 Poles, 1-Phase, Line/Load Lugs, 3/0 AWG to 350 kcmil Al/Cu Wire, NEMA AB1, Plug-In Mount, 104 deg F, 11.48 in H x 4.48 in W x 5.87 in D
Square D™ I-Line™ PowerPact™ Molded Case Circuit Breaker, Type JGA, 600 VAC/500 VDC, 225 A, 50/60 Hz, 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC/20 kA at 250 VDC Interrupt, J Frame, Thermal Magnetic Trip, 1125 to 2250 A Trip, 2 Poles, 1-Phase, Line/Load Lugs, 3/0 AWG to 350 kcmil Al/Cu Wire, NEMA AB1, Plug-In Mount, 104 deg F, 11.48 in H x 4.48 in W x 5.87 in D
Actuator Type Toggle Alternate Catalog Number JGA262254 Application PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION ARRA Compliant N Buy American Compliant N Catalog Number JGA262254 Connection AWG 3/0...350 KCMIL ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD Connection Type Line/Load Lugs Country of Origin US Currency USD Dimensions 11.48 in H x 4.48 in W x 5.87 in D EU RoHS Indicator Y Frame J Frame Frequency Rating 50/60 Hz Gross Weight Per Pack 4.5000 lb Gross Weight per Pack Metric 2.04 Gross Weight UOM Metric kg Height 5.5118 in Height [Metric] 13.6530 cm Item Group 01117 Length 14.5669 in Length [Metric] 37.1480 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=425477&lang=en-us Number Of Poles 2 Operating Temperature 40 °C Phase 1 pH Returnable Y Standard CCC-IEC-CSA-CE-UL LISTED Sub Brand POWERPACT Temperature Rating 104 °F Trip Range 1125 to 2250 A Type Type JGA UNSPSC 39121601 UPC 11 78590188216 UPC 12 785901882169 Warranty Description Contractual Warranty:18 months Width 8.2677 in Width [Metric] 20.6380 cm Wire Size 3/0 AWG to 350 kcmil Al/Cu Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 225 A Interrupt Rating 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC/20 kA at 250 VDC Trip Type Thermal Magnetic Voltage Rating 600 VAC/500 VDC PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION I-LINE Rated current from 70 to 250 A Breaking capacity from 18 to 65 kA at 480 VAC Common accessories and auxiliaries with other PowerPact™ frames 20 kA at 250 VDC, 65 kA at 240 VAC, 35 kA at 480 VAC, 18 kA at 600 VAC, 20 kA at 500 VDC interrupt rating Easy to install, extremely versatile, a wide variety of terminal Flexible and simple offer, with proven performance Direct access to energy metering and energy efficiency
