Square D™ I-Line™ PowerPact™ JDA262252 Type JDA Molded Case Circuit Breaker, 600 VAC/250 VDC, 225 A, 2 Poles
Custom_Product_Images_Illustration
Square D™ I-Line™ PowerPact™ JDA262252 Type JDA Molded Case Circuit Breaker, 600 VAC/250 VDC, 225 A, 2 Poles
SKU536341
MFGR #JDA262252
Your Cost: $1,455.07/ea
List: Square D JDA262252 MOLDED CASE CIRCUIT BREAKER 600V 225A,1125...2250 A,225 A,2-Pole,225 A,25 kA 240 V AC-18 kA 480 V AC-14 kA 600 V AC,600 V AC,600 V AC,I-Line Connection (ON end) - Lugs (OFF end) AC,J-Frame,Powerpact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,circuit breaker,plug-in,thermal-magnetic
Square D JDA262252 MOLDED CASE CIRCUIT BREAKER 600V 225A,1125...2250 A,225 A,2-Pole,225 A,25 kA 240 V AC-18 kA 480 V AC-14 kA 600 V AC,600 V AC,600 V AC,I-Line Connection (ON end) - Lugs (OFF end) AC,J-Frame,Powerpact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,circuit breaker,plug-in,thermal-magnetic
Alternate Catalog Number JDA262252 Application PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION ARRA Compliant N Buy American Compliant N Catalog Number JDA262252 Connection AWG 3/0...350 KCMIL ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD Country of Origin US Currency USD Dimensions 11.48 in H x 4.48 in W x 5.87 in D EU RoHS Indicator Y Frame D Gross Weight Per Pack 4.5000 lb Gross Weight per Pack Metric 2.04 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 13.9700 in Height [Metric] 13.9700 cm Item Group 01112 Length 38.1000 in Length [Metric] 38.1000 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=424927&lang=en-us Mounting Type Plug-In Number Of Poles 2 Operating Temperature 40 °C Returnable Y Standard CE-CCC-UL LISTED-IEC-CSA Sub Brand POWERPACT Temperature Rating 104 °F Trip Range 1125 A,225 A,2250 A Type CIRCUIT BREAKER UNSPSC 39121601 UPC 11 78590191219 UPC 12 785901912194 Warranty Description Contractual Warranty:18 months Width 21.5900 in Width [Metric] 21.5900 cm Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 225 A Interrupt Rating 25 KA 240 V AC-18 KA 480 V AC-14 KA 600 V AC-20 KA 250 V DC,250 V DC-600 V AC Trip Type Thermal-magnetic Voltage Rating 600 V AC-250 V DC PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION I-LINE Common mounting holes, handle locations and trim dimensions across the range allow design standardization for PowerPact™ H and J-frame circuit breakers Common accessories across the range of PowerPact™ molded case circuit breakers allow users to make late specification changes A wide range of field installable accessories allows customers to reduce inventory without sacrificing flexibility Equipped with a unique snap-in terminal design that makes converting between busbar and lug options easy Easy to install, extremely versatile, a wide variety of terminal Flexible and simple offer, with proven performance Direct access to energy metering and energy efficiency
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | JDA262252 |
| Application | PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | JDA262252 |
| Connection | AWG 3/0...350 KCMIL ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 11.48 in H x 4.48 in W x 5.87 in D |
| EU RoHS Indicator | Y |
| Frame | D |
| Gross Weight Per Pack | 4.5000 lb |
| Gross Weight per Pack Metric | 2.04 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 13.9700 in |
| Height [Metric] | 13.9700 cm |
| Item Group | 01112 |
| Length | 38.1000 in |
| Length [Metric] | 38.1000 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=424927&lang=en-us |
| Mounting Type | Plug-In |
| Number Of Poles | 2 |
| Operating Temperature | 40 °C |
| Returnable | Y |
| Standard | CE-CCC-UL LISTED-IEC-CSA |
| Sub Brand | POWERPACT |
| Temperature Rating | 104 °F |
| Trip Range | 1125 A,225 A,2250 A |
| Type | CIRCUIT BREAKER |
| UNSPSC | 39121601 |
| UPC 11 | 78590191219 |
| UPC 12 | 785901912194 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 21.5900 in |
| Width [Metric] | 21.5900 cm |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 225 A |
| Interrupt Rating | 25 KA 240 V AC-18 KA 480 V AC-14 KA 600 V AC-20 KA 250 V DC,250 V DC-600 V AC |
| Trip Type | Thermal-magnetic |
| Voltage Rating | 600 V AC-250 V DC |
| PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| I-LINE |
| Common mounting holes, handle locations and trim dimensions across the range allow design standardization for PowerPact™ H and J-frame circuit breakers |
| Common accessories across the range of PowerPact™ molded case circuit breakers allow users to make late specification changes |
| A wide range of field installable accessories allows customers to reduce inventory without sacrificing flexibility |
| Equipped with a unique snap-in terminal design that makes converting between busbar and lug options easy |
| Easy to install, extremely versatile, a wide variety of terminal |
| Flexible and simple offer, with proven performance |
| Direct access to energy metering and energy efficiency |
