Square D™ I-Line™ PowerPact™ JDA262251 Type JDA Molded Case Circuit Breaker, 600 VAC/250 VDC, 225 A, 2 Poles
Custom_Product_Images_Illustration
Square D™ I-Line™ PowerPact™ JDA262251 Type JDA Molded Case Circuit Breaker, 600 VAC/250 VDC, 225 A, 2 Poles
SKU536339
MFGR #JDA262251
Your Cost: $1,635.74/ea
List: Square D JDA262251 MOLDED CASE CIRCUIT BREAKER 600V 225A,1125...2250 A,225 A,18 kA 480 V AC-25 kA 240 V AC-14 kA 600 V AC,600 V AC,2-Pole,225 A,600 V AC,I-Line Connection (ON end) - Lugs (OFF end) AB,J-Frame,Powerpact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,circuit breaker,plug-in,thermal-magnetic
Square D JDA262251 MOLDED CASE CIRCUIT BREAKER 600V 225A,1125...2250 A,225 A,18 kA 480 V AC-25 kA 240 V AC-14 kA 600 V AC,600 V AC,2-Pole,225 A,600 V AC,I-Line Connection (ON end) - Lugs (OFF end) AB,J-Frame,Powerpact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,circuit breaker,plug-in,thermal-magnetic
Actuator Type Toggle Alternate Catalog Number JDA262251 Application PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION ARRA Compliant N Buy American Compliant N Catalog Number JDA262251 Connection AWG 3/0...350 KCMIL ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD Connection Type Line/Load Lugs Country of Origin US Currency USD Dimensions 11.48 in H x 4.48 in W x 5.87 in D EU RoHS Indicator Y Frame J Frame Frequency Rating 50/60 Hz Gross Weight Per Pack 4.5000 lb Gross Weight per Pack Metric 2.04 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 13.6530 in Height [Metric] 13.6530 cm Item Group 01112 Length 37.1480 in Length [Metric] 37.1480 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=424923&lang=en-us Number Of Poles 2 Operating Temperature 40 °C Phase 1 pH Returnable Y Standard UL LISTED-CSA-CCC-CE-IEC Sub Brand POWERPACT Temperature Rating 104 °F Trip Range 1125 to 2250 A Type Type JDA UNSPSC 39121601 UPC 11 78590191218 UPC 12 785901912187 Warranty Description Contractual Warranty:18 months Width 20.6380 in Width [Metric] 20.6380 cm Wire Size 3/0 AWG to 350 kcmil Al/Cu Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 225 A Interrupt Rating 25 kA at 240 VAC/18 kA at 480 VAC/14 kA at 600 VAC/20 kA at 250 VDC Trip Type Thermal Magnetic Voltage Rating 600 VAC/250 VDC PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION I-LINE Rated current from 70 to 250 A Breaking capacity from 18 to 65 kA at 480 VAC Common accessories and auxiliaries with other PowerPact™ frames 25 kA at 240 VAC, 18 kA at 480 VAC, 14 kA at 600 VAC, 20 kA at 250 VDC interrupt rating Easy to install, extremely versatile, a wide variety of terminal Flexible and simple offer, with proven performance Direct access to energy metering and energy efficiency
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator Type | Toggle |
| Alternate Catalog Number | JDA262251 |
| Application | PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | JDA262251 |
| Connection | AWG 3/0...350 KCMIL ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD |
| Connection Type | Line/Load Lugs |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 11.48 in H x 4.48 in W x 5.87 in D |
| EU RoHS Indicator | Y |
| Frame | J Frame |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 4.5000 lb |
| Gross Weight per Pack Metric | 2.04 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 13.6530 in |
| Height [Metric] | 13.6530 cm |
| Item Group | 01112 |
| Length | 37.1480 in |
| Length [Metric] | 37.1480 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=424923&lang=en-us |
| Number Of Poles | 2 |
| Operating Temperature | 40 °C |
| Phase | 1 pH |
| Returnable | Y |
| Standard | UL LISTED-CSA-CCC-CE-IEC |
| Sub Brand | POWERPACT |
| Temperature Rating | 104 °F |
| Trip Range | 1125 to 2250 A |
| Type | Type JDA |
| UNSPSC | 39121601 |
| UPC 11 | 78590191218 |
| UPC 12 | 785901912187 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 20.6380 in |
| Width [Metric] | 20.6380 cm |
| Wire Size | 3/0 AWG to 350 kcmil Al/Cu |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 225 A |
| Interrupt Rating | 25 kA at 240 VAC/18 kA at 480 VAC/14 kA at 600 VAC/20 kA at 250 VDC |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 600 VAC/250 VDC |
| PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| I-LINE |
| Rated current from 70 to 250 A |
| Breaking capacity from 18 to 65 kA at 480 VAC |
| Common accessories and auxiliaries with other PowerPact™ frames |
| 25 kA at 240 VAC, 18 kA at 480 VAC, 14 kA at 600 VAC, 20 kA at 250 VDC interrupt rating |
| Easy to install, extremely versatile, a wide variety of terminal |
| Flexible and simple offer, with proven performance |
| Direct access to energy metering and energy efficiency |
