Square D™ I-Line™ PowerPact™ HLA261251 Molded Case Circuit Breaker, 600 VAC, 125 A, 2 Poles, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Square D™ I-Line™ PowerPact™ HLA261251 Molded Case Circuit Breaker, 600 VAC, 125 A, 2 Poles, Thermal Magnetic Trip
SKUPDW~6908808
MFGR #HLA261251
Price Not Available
The PowerPact™ H, J and L-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. H and J-frame circuit breakers are available with either thermal-magnetic or Micrologic™ electronic trip units. L-frame circuit breakers are available with Micrologic™ electronic trip units only. H and J-frame circuit breakers with thermal-magnetic trip units contain individual thermal (overload) and instantaneous (short circuit) sensing elements in each pole. The amperage ratings of the thermal trip elements are calibrated at 104 deg F free air ambient temperature. Per the National Electric Code® (NEC®) and the Canadian Electrical Code®, standard circuit breakers may only be applied continuously at up to 80% of their rating. Circuit breakers rated for 100% operation are available but require specially-designed enclosures and 194 deg F rated wire.
The PowerPact™ H, J and L-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. H and J-frame circuit breakers are available with either thermal-magnetic or Micrologic™ electronic trip units. L-frame circuit breakers are available with Micrologic™ electronic trip units only. H and J-frame circuit breakers with thermal-magnetic trip units contain individual thermal (overload) and instantaneous (short circuit) sensing elements in each pole. The amperage ratings of the thermal trip elements are calibrated at 104 deg F free air ambient temperature. Per the National Electric Code® (NEC®) and the Canadian Electrical Code®, standard circuit breakers may only be applied continuously at up to 80% of their rating. Circuit breakers rated for 100% operation are available but require specially-designed enclosures and 194 deg F rated wire.
Alternate Catalog Number HLA261251 ARRA Compliant N Buy American Compliant N Catalog Number HLA261251 Connection AWG 14...AWG 3/0 ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD Connection Type Line/Load Lug Country of Origin US Currency USD Dimensions 6.4 in H x 2.74 in W x 4.36 in D Enclosure Type NEMA AB1 EU RoHS Indicator Y Frame H Frequency Rating 50/60 Hz Gross Weight Per Pack 0.0181 lb Gross Weight per Pack Metric 1.81 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 13.6530 in Height [Metric] 13.6530 cm Item Group 01122 Length 37.1480 in Length [Metric] 37.1480 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=424243&lang=en-us Mounting Type Surface Number Of Poles 2 Operating Temperature 40 °C Phase AB Returnable Y Standard UL LISTED-IEC-CE-CSA Temperature Rating 104 °F Trip Range 900 to 1700 A Type Type HLA UNSPSC 39121601 UPC 11 78590182517 UPC 12 785901825173 Warranty Description Contractual Warranty:18 months Width 20.6380 in Width [Metric] 20.6380 cm Wire Size 14 to 3/0 AWG Al/Cu Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 125 A Interrupt Rating 125 kA at 240 VAC/100 kA at 480 VAC/50 kA at 600 VAC/20 kA at 250 VDC/50 kA at 500 VDC Trip Type Thermal Magnetic Voltage Rating 600 VAC/250 to 500 VDC I-LINE Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields Flexible and simple offer, with proven performance Direct access to energy metering and energy efficiency AB-phase connection 125 kA at 240 VAC, 100 kA at 480 VAC, 50 kA at 600 VAC, 20 kA at 250 VDC, 50 kA at 500 VDC interrupt rating
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Alternate Catalog Number | HLA261251 |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | HLA261251 |
| Connection | AWG 14...AWG 3/0 ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD |
| Connection Type | Line/Load Lug |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 6.4 in H x 2.74 in W x 4.36 in D |
| Enclosure Type | NEMA AB1 |
| EU RoHS Indicator | Y |
| Frame | H |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 0.0181 lb |
| Gross Weight per Pack Metric | 1.81 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 13.6530 in |
| Height [Metric] | 13.6530 cm |
| Item Group | 01122 |
| Length | 37.1480 in |
| Length [Metric] | 37.1480 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=424243&lang=en-us |
| Mounting Type | Surface |
| Number Of Poles | 2 |
| Operating Temperature | 40 °C |
| Phase | AB |
| Returnable | Y |
| Standard | UL LISTED-IEC-CE-CSA |
| Temperature Rating | 104 °F |
| Trip Range | 900 to 1700 A |
| Type | Type HLA |
| UNSPSC | 39121601 |
| UPC 11 | 78590182517 |
| UPC 12 | 785901825173 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 20.6380 in |
| Width [Metric] | 20.6380 cm |
| Wire Size | 14 to 3/0 AWG Al/Cu |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 125 A |
| Interrupt Rating | 125 kA at 240 VAC/100 kA at 480 VAC/50 kA at 600 VAC/20 kA at 250 VDC/50 kA at 500 VDC |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 600 VAC/250 to 500 VDC |
| I-LINE |
| Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields |
| Flexible and simple offer, with proven performance |
| Direct access to energy metering and energy efficiency |
| AB-phase connection |
| 125 kA at 240 VAC, 100 kA at 480 VAC, 50 kA at 600 VAC, 20 kA at 250 VDC, 50 kA at 500 VDC interrupt rating |
