Square D™ I-Line™ PowerPact™ HJA260302 Molded Case Circuit Breaker, 600 VAC, 30 A, 2 Poles, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Square D™ I-Line™ PowerPact™ HJA260302 Molded Case Circuit Breaker, 600 VAC, 30 A, 2 Poles, Thermal Magnetic Trip
SKU1135046
MFGR #HJA260302
Your Cost: $1,519.12/ea
List: The PowerPact™ H, J and L-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. H and J-frame circuit breakers are available with either thermal-magnetic or Micrologic™ electronic trip units. L-frame circuit breakers are available with Micrologic™ electronic trip units only. H and J-frame circuit breakers with thermal-magnetic trip units contain individual thermal (overload) and instantaneous (short circuit) sensing elements in each pole. The amperage ratings of the thermal trip elements are calibrated at 104 deg F free air ambient temperature. Per the National Electric Code® (NEC®) and the Canadian Electrical Code®, standard circuit breakers may only be applied continuously at up to 80% of their rating. Circuit breakers rated for 100% operation are available but require specially-designed enclosures and 194 deg F rated wire.
The PowerPact™ H, J and L-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. H and J-frame circuit breakers are available with either thermal-magnetic or Micrologic™ electronic trip units. L-frame circuit breakers are available with Micrologic™ electronic trip units only. H and J-frame circuit breakers with thermal-magnetic trip units contain individual thermal (overload) and instantaneous (short circuit) sensing elements in each pole. The amperage ratings of the thermal trip elements are calibrated at 104 deg F free air ambient temperature. Per the National Electric Code® (NEC®) and the Canadian Electrical Code®, standard circuit breakers may only be applied continuously at up to 80% of their rating. Circuit breakers rated for 100% operation are available but require specially-designed enclosures and 194 deg F rated wire.
Alternate Catalog Number HJA260302 ARRA Compliant N Buy American Compliant N Catalog Number HJA260302 Connection AWG 14...AWG 3/0 ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD Country of Origin US Currency USD EU RoHS Indicator Y Frame J Gross Weight Per Pack 5.2900 lb Gross Weight per Pack Metric 2.40 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 13.6530 in Height [Metric] 13.6530 cm Item Group 01117 Length 37.1480 in Length [Metric] 37.1480 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=423169&lang=en-us Number Of Poles 2 Operating Temperature 40 °C Phase AC Returnable Y Standard IEC-UL LISTED-CSA-CE Standards ARRA, Buy American Act Compliant, CSA C22.2 No. 5 File No. LR40970, CCC, CE, Federal Specification W-C-375B/GEN, IEC 60947-2, UL 489 File No. E10027 Trip Range 30 A,350 A,750 A Type CIRCUIT BREAKER UNSPSC 39121616 UPC 11 78590160106 UPC 12 785901601067 Warranty Description Contractual Warranty:18 months Width 20.6380 in Width [Metric] 20.6380 cm Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 30 A Interrupt Rating 250 V DC-600 V AC,65 KA AT 480 V AC-25 KA AT 600 V AC-100 KA AT 240 V AC-20 KA AT 250 V DC Trip Type Thermal-magnetic Voltage Rating 250 V DC-600 V AC I-LINE Easy to install, extremely versatile, a wide variety of terminal Flexible and simple offer, with proven performance Direct access to energy metering and energy efficiency
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Alternate Catalog Number | HJA260302 |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | HJA260302 |
| Connection | AWG 14...AWG 3/0 ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD |
| Country of Origin | US |
| Currency | USD |
| EU RoHS Indicator | Y |
| Frame | J |
| Gross Weight Per Pack | 5.2900 lb |
| Gross Weight per Pack Metric | 2.40 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 13.6530 in |
| Height [Metric] | 13.6530 cm |
| Item Group | 01117 |
| Length | 37.1480 in |
| Length [Metric] | 37.1480 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=423169&lang=en-us |
| Number Of Poles | 2 |
| Operating Temperature | 40 °C |
| Phase | AC |
| Returnable | Y |
| Standard | IEC-UL LISTED-CSA-CE |
| Standards | ARRA, Buy American Act Compliant, CSA C22.2 No. 5 File No. LR40970, CCC, CE, Federal Specification W-C-375B/GEN, IEC 60947-2, UL 489 File No. E10027 |
| Trip Range | 30 A,350 A,750 A |
| Type | CIRCUIT BREAKER |
| UNSPSC | 39121616 |
| UPC 11 | 78590160106 |
| UPC 12 | 785901601067 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 20.6380 in |
| Width [Metric] | 20.6380 cm |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 30 A |
| Interrupt Rating | 250 V DC-600 V AC,65 KA AT 480 V AC-25 KA AT 600 V AC-100 KA AT 240 V AC-20 KA AT 250 V DC |
| Trip Type | Thermal-magnetic |
| Voltage Rating | 250 V DC-600 V AC |
| I-LINE |
| Easy to install, extremely versatile, a wide variety of terminal |
| Flexible and simple offer, with proven performance |
| Direct access to energy metering and energy efficiency |
