Square D™
Square D™ I-Line™ PowerPact™ HJA260254 Molded Case Circuit Breaker, 600 VAC, 25 A, 2 Poles, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Square D™
Square D™ I-Line™ PowerPact™ HJA260254 Molded Case Circuit Breaker, 600 VAC, 25 A, 2 Poles, Thermal Magnetic Trip
SKUPDW~11720989
MFGR #HJA260254
$/ea
Schneider Electric HJA260254 MOLDED CASE CIRCUIT BREAKER 600V 25A,100 kA 240 V AC-25 kA 600 V AC-65 kA 480 V AC,600 V AC,25 A,25 A,350 A,750 A,600 V AC,J,circuit breaker,plug-in,thermal-magnetic
Schneider Electric HJA260254 MOLDED CASE CIRCUIT BREAKER 600V 25A,100 kA 240 V AC-25 kA 600 V AC-65 kA 480 V AC,600 V AC,25 A,25 A,350 A,750 A,600 V AC,J,circuit breaker,plug-in,thermal-magnetic
Actuator Type Toggle Alternate Catalog Number HJA260254 ARRA Compliant N Buy American Compliant N Catalog Number HJA260254 Connection AWG 14...AWG 3/0 ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD Connection Type Line/Load Lug Country of Origin US Currency USD Dimensions 6.4 in H x 2.74 in W x 4.36 in D EU RoHS Indicator Y Frame H Frequency Rating 50/60 Hz Gross Weight Per Pack 0.0181 lb Gross Weight per Pack Metric 1.81 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 13.6530 CM Height [Metric] 13.6530 cm Item Group 01117 Length 37.1480 CM Length [Metric] 37.1480 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=423159&lang=en-us Mounting Type Surface Number Of Poles 2 Operating Temperature 40 °C Phase 1 pH Returnable Y Standard UL LISTED-CE-IEC-CSA Temperature Rating 104 °F Trip Range 350 to 750 A Type Type HJA UNSPSC 39121601 UPC 11 78590148371 UPC 12 785901483717 Warranty Description Contractual Warranty:18 months Width 21.0000 CM Width [Metric] 20.6380 cm Wire Size 14 to 3/0 AWG Al/Cu Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 25 A Interrupt Rating 100 kA at 240 VAC/65 kA at 480 VAC/25 kA at 600 VAC/20 kA at 250 VDC Trip Type Thermal Magnetic Voltage Rating 600 VAC/250 VDC I-LINE Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields Flexible and simple offer, with proven performance Direct access to energy metering and energy efficiency 65 kA at 480 VAC, 25 kA at 600 VAC, 100 kA at 240 VAC, 20 kA at 250 VDC interrupt rating
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Actuator Type | Toggle |
| Alternate Catalog Number | HJA260254 |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | HJA260254 |
| Connection | AWG 14...AWG 3/0 ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD |
| Connection Type | Line/Load Lug |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 6.4 in H x 2.74 in W x 4.36 in D |
| EU RoHS Indicator | Y |
| Frame | H |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 0.0181 lb |
| Gross Weight per Pack Metric | 1.81 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 13.6530 CM |
| Height [Metric] | 13.6530 cm |
| Item Group | 01117 |
| Length | 37.1480 CM |
| Length [Metric] | 37.1480 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=423159&lang=en-us |
| Mounting Type | Surface |
| Number Of Poles | 2 |
| Operating Temperature | 40 °C |
| Phase | 1 pH |
| Returnable | Y |
| Standard | UL LISTED-CE-IEC-CSA |
| Temperature Rating | 104 °F |
| Trip Range | 350 to 750 A |
| Type | Type HJA |
| UNSPSC | 39121601 |
| UPC 11 | 78590148371 |
| UPC 12 | 785901483717 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 21.0000 CM |
| Width [Metric] | 20.6380 cm |
| Wire Size | 14 to 3/0 AWG Al/Cu |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 25 A |
| Interrupt Rating | 100 kA at 240 VAC/65 kA at 480 VAC/25 kA at 600 VAC/20 kA at 250 VDC |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 600 VAC/250 VDC |
| I-LINE |
| Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields |
| Flexible and simple offer, with proven performance |
| Direct access to energy metering and energy efficiency |
| 65 kA at 480 VAC, 25 kA at 600 VAC, 100 kA at 240 VAC, 20 kA at 250 VDC interrupt rating |
