Square D™
Square D™ I-Line™ PowerPact™ HGA36025 Type HGA Molded Case Circuit Breaker, 600 VAC/250 to 500 VDC, 25 A, 3 Poles
Custom_Product_Images_Illustration
Square D™
Square D™ I-Line™ PowerPact™ HGA36025 Type HGA Molded Case Circuit Breaker, 600 VAC/250 to 500 VDC, 25 A, 3 Poles
SKU429622
MFGR #HGA36025
$/ea
Square D HGA36025 MOLDED CASE CIRCUIT BREAKER 600V 25A,25 A,25 A,350 A,750 A,3-Pole,600 V AC,600 V AC,65 kA 240 V AC-35 kA 480 V AC-18 kA 600 V AC,G,I-Line Connection (ON end) - Lugs (OFF end) ABC,PowerPact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,circuit breaker,plug-in,thermal-magnetic
Square D HGA36025 MOLDED CASE CIRCUIT BREAKER 600V 25A,25 A,25 A,350 A,750 A,3-Pole,600 V AC,600 V AC,65 kA 240 V AC-35 kA 480 V AC-18 kA 600 V AC,G,I-Line Connection (ON end) - Lugs (OFF end) ABC,PowerPact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,circuit breaker,plug-in,thermal-magnetic
Alternate Catalog Number HGA36025 Application PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION ARRA Compliant N Buy American Compliant N Catalog Number HGA36025 Connection AWG 14...AWG 3/0 ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD Country of Origin US Currency USD EU RoHS Indicator Y Frame G Gross Volume Per Pack 789.58 Gross Volume per Pack Metric 12938.83 Gross Volume UOM CI Gross Volume UOM Metric cm3 Gross Weight Per Pack 0.0250 lb Gross Weight per Pack Metric 2.50 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 16.0020 in Height [Metric] 16.0000 cm Item Group 01117 Length 38.3540 in Length [Metric] 38.3500 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=422417&lang=en-us Number Of Poles 3 Operating Temperature 40 °C Phase ABC Returnable Y Standard IEC-UL LISTED-CSA-CE Standards UL 498 File No. E10027, CCC, CE, CSA C22.2 No. 5 File No. LR40970, NMX J-266, IEC 60947-2, NOM, Federal Specified W-C-375B/GEN, HACR Rated, RoHS, ARRA, Buy American Act Compliant Sub Brand POWERPACT Trip Range 25 A,350 A,750 A Type Circuit Breaker UNSPSC 39121601 UPC 11 78590170056 UPC 12 785901700562 Warranty Description Contractual Warranty:18 months Width 21.0820 in Width [Metric] 21.0800 cm Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 25 A Interrupt Rating 250 V DC-500 V DC-600 V AC,65 KA AT 240 V AC-35 KA AT 480 V AC-18 KA AT 600 V AC-20 KA AT 500 V DC-20 KA AT 250 V DC Trip Type Thermal-magnetic Voltage Rating 250 V DC-600 V AC-500 V DC VAC PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION I-LINE Easy to install, extremely versatile, a wide variety of terminal Flexible and simple offer, with proven performance Direct access to energy metering and energy efficiency
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | HGA36025 |
| Application | PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | HGA36025 |
| Connection | AWG 14...AWG 3/0 ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD |
| Country of Origin | US |
| Currency | USD |
| EU RoHS Indicator | Y |
| Frame | G |
| Gross Volume Per Pack | 789.58 |
| Gross Volume per Pack Metric | 12938.83 |
| Gross Volume UOM | CI |
| Gross Volume UOM Metric | cm3 |
| Gross Weight Per Pack | 0.0250 lb |
| Gross Weight per Pack Metric | 2.50 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 16.0020 in |
| Height [Metric] | 16.0000 cm |
| Item Group | 01117 |
| Length | 38.3540 in |
| Length [Metric] | 38.3500 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=422417&lang=en-us |
| Number Of Poles | 3 |
| Operating Temperature | 40 °C |
| Phase | ABC |
| Returnable | Y |
| Standard | IEC-UL LISTED-CSA-CE |
| Standards | UL 498 File No. E10027, CCC, CE, CSA C22.2 No. 5 File No. LR40970, NMX J-266, IEC 60947-2, NOM, Federal Specified W-C-375B/GEN, HACR Rated, RoHS, ARRA, Buy American Act Compliant |
| Sub Brand | POWERPACT |
| Trip Range | 25 A,350 A,750 A |
| Type | Circuit Breaker |
| UNSPSC | 39121601 |
| UPC 11 | 78590170056 |
| UPC 12 | 785901700562 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 21.0820 in |
| Width [Metric] | 21.0800 cm |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 25 A |
| Interrupt Rating | 250 V DC-500 V DC-600 V AC,65 KA AT 240 V AC-35 KA AT 480 V AC-18 KA AT 600 V AC-20 KA AT 500 V DC-20 KA AT 250 V DC |
| Trip Type | Thermal-magnetic |
| Voltage Rating | 250 V DC-600 V AC-500 V DC VAC |
| PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| I-LINE |
| Easy to install, extremely versatile, a wide variety of terminal |
| Flexible and simple offer, with proven performance |
| Direct access to energy metering and energy efficiency |
