Square D™ I-Line™ PowerPact™ HDA261002 Molded Case Circuit Breaker, 600 VAC, 100 A, 2 Poles, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Square D™ I-Line™ PowerPact™ HDA261002 Molded Case Circuit Breaker, 600 VAC, 100 A, 2 Poles, Thermal Magnetic Trip
SKU592612
MFGR #HDA261002
Your Cost: $693.44/ea
List: Square D HDA261002 by Schneider Electric MOLDED CASE CIRCUIT BREAKER 600V 100A,-13F and 158F (-25 C and +70 C),100A,2,25kA240VAC - 18kA480VAC - 14kA600VAC,50/60Hz,600 Vac/250 Vdc,H-Frame,Hold 900A - Trip 1700A,I-Line Connection (ON end) - Lugs (OFF end) AC,I-Line Plug-On,Molded Case Circuit Breaker,PowerPact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated - CCC
Square D HDA261002 by Schneider Electric MOLDED CASE CIRCUIT BREAKER 600V 100A,-13F and 158F (-25 C and +70 C),100A,2,25kA240VAC - 18kA480VAC - 14kA600VAC,50/60Hz,600 Vac/250 Vdc,H-Frame,Hold 900A - Trip 1700A,I-Line Connection (ON end) - Lugs (OFF end) AC,I-Line Plug-On,Molded Case Circuit Breaker,PowerPact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated - CCC
Alternate Catalog Number HDA261002 Application PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION ARRA Compliant N Buy American Compliant N Catalog Number HDA261002 Connection I-LINE CONNECTION (ON END) - LUGS (OFF END) AC Connection Type Line/Load Lug Country of Origin MX Currency USD Dimensions 6.4 in H x 2.74 in W x 4.36 in D Enclosure Type NEMA AB1 EU RoHS Indicator Y Frame H Frequency Rating 50/60 Hz Gross Volume Per Pack 551.90 Gross Volume per Pack Metric 9044.07 Gross Volume UOM CI Gross Volume UOM Metric cm3 Gross Weight Per Pack 4.0600 lb Gross Weight per Pack Metric 1.84 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 10.9220 in Height [Metric] 11.4000 cm Item Group 01112 Length 38.3540 in Length [Metric] 37.8000 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=421273&lang=en-us Mounting Type Surface Number Of Poles 2 Operating Temperature -13 to 158F (-25 to 70C) °C Phase 1 pH Returnable Y Standard UL LISTED - CSA CERTIFIED - IEC RATED - CCC Sub Brand POWERPACT Substitute Product Catalog Number PDC3HD2 Temperature Rating 104 °F Trip Range 900 to 1700 A Type MOLDED CASE CIRCUIT BREAKER UNSPSC 39121601 UPC 11 78590175038 UPC 12 785901750383 Warranty Description Contractual Warranty:18 months Width 21.5900 in Width [Metric] 21.8000 cm Wire Size 14 to 3/0 AWG Al/Cu Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 100 A Interrupt Rating 25 kA at 240 VAC/18 kA at 480 VAC/14 kA at 600 VAC/20 kA at 250 VDC Trip Type Thermal Magnetic Voltage Rating 600 VAC PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION I-LINE PLUG-ON Easy to install, extremely versatile, a wide variety of terminal Flexible and simple offer, with proven performance Direct access to energy metering and energy efficiency
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | HDA261002 |
| Application | PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | HDA261002 |
| Connection | I-LINE CONNECTION (ON END) - LUGS (OFF END) AC |
| Connection Type | Line/Load Lug |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 6.4 in H x 2.74 in W x 4.36 in D |
| Enclosure Type | NEMA AB1 |
| EU RoHS Indicator | Y |
| Frame | H |
| Frequency Rating | 50/60 Hz |
| Gross Volume Per Pack | 551.90 |
| Gross Volume per Pack Metric | 9044.07 |
| Gross Volume UOM | CI |
| Gross Volume UOM Metric | cm3 |
| Gross Weight Per Pack | 4.0600 lb |
| Gross Weight per Pack Metric | 1.84 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 10.9220 in |
| Height [Metric] | 11.4000 cm |
| Item Group | 01112 |
| Length | 38.3540 in |
| Length [Metric] | 37.8000 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=421273&lang=en-us |
| Mounting Type | Surface |
| Number Of Poles | 2 |
| Operating Temperature | -13 to 158F (-25 to 70C) °C |
| Phase | 1 pH |
| Returnable | Y |
| Standard | UL LISTED - CSA CERTIFIED - IEC RATED - CCC |
| Sub Brand | POWERPACT |
| Substitute Product Catalog Number | PDC3HD2 |
| Temperature Rating | 104 °F |
| Trip Range | 900 to 1700 A |
| Type | MOLDED CASE CIRCUIT BREAKER |
| UNSPSC | 39121601 |
| UPC 11 | 78590175038 |
| UPC 12 | 785901750383 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 21.5900 in |
| Width [Metric] | 21.8000 cm |
| Wire Size | 14 to 3/0 AWG Al/Cu |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 100 A |
| Interrupt Rating | 25 kA at 240 VAC/18 kA at 480 VAC/14 kA at 600 VAC/20 kA at 250 VDC |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 600 VAC |
| PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| I-LINE PLUG-ON |
| Easy to install, extremely versatile, a wide variety of terminal |
| Flexible and simple offer, with proven performance |
| Direct access to energy metering and energy efficiency |
