Square D™ I-Line™ PowerPact™ HDA260702 Type HDA Molded Case Circuit Breaker, 600 VAC/250 VDC, 70 A, 2 Poles
Custom_Product_Images_Illustration
Square D™
Square D™ I-Line™ PowerPact™ HDA260702 Type HDA Molded Case Circuit Breaker, 600 VAC/250 VDC, 70 A, 2 Poles
SKU699402
MFGR #HDA260702
Your Cost: $693.44/ea
List: Square D HDA260702 MOLDED CASE CIRCUIT BREAKER 600V 70A,1450 A,70 A,800 A,2-Pole,25 kA 240 V AC-18 kA 480 V AC-14 kA 600 V AC,600 V AC,600 V AC,70 A,D,I-Line Connection (ON end) - Lugs (OFF end) AC,PowerPact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,circuit breaker,plug-in,thermal-magnetic
Square D HDA260702 MOLDED CASE CIRCUIT BREAKER 600V 70A,1450 A,70 A,800 A,2-Pole,25 kA 240 V AC-18 kA 480 V AC-14 kA 600 V AC,600 V AC,600 V AC,70 A,D,I-Line Connection (ON end) - Lugs (OFF end) AC,PowerPact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,circuit breaker,plug-in,thermal-magnetic
Alternate Catalog Number HDA260702 Application PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION ARRA Compliant N Buy American Compliant N Catalog Number HDA260702 Connection AWG 14...AWG 3/0 ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD Connection Type I-Line™/Load Lug/Drawout Country of Origin US Currency USD Dimensions 9.73 in H x 2.94 in W x 4.8 in D Enclosure Type NEMA AB1 EU RoHS Indicator Y Frame H Frequency Rating 50/60 Hz Gross Weight Per Pack 3.0000 lb Gross Weight per Pack Metric 1.36 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 9.8430 in Height [Metric] 9.8430 cm Item Group 01112 Length 37.1480 in Length [Metric] 37.1480 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=421235&lang=en-us Mounting Type Plug-In Number Of Poles 2 Operating Temperature 40 °C Phase 1 pH Returnable Y Standard IEC-UL LISTED-CE-CSA Sub Brand POWERPACT Temperature Rating 104 °F Trip Range 800 to 1450 A Type Type HDA UNSPSC 39121601 UPC 11 78590163261 UPC 12 785901632610 Warranty Description Contractual Warranty:18 months Width 20.6380 in Width [Metric] 20.6380 cm Wire Size 14 to 3/0 AWG Al/Cu Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 70 A Interrupt Rating 18/25/14/20 kA Trip Type Thermal Magnetic Voltage Rating 600 VAC/250 VDC PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION I-LINE Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields Flexible and simple offer, with proven performance Direct access to energy metering and energy efficiency AC-phase connection 18 kA at 480 VAC, 25 kA at 240 VAC, 14 kA at 600 VAC, 20 kA at 250 VDC interrupt rating
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | HDA260702 |
| Application | PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | HDA260702 |
| Connection | AWG 14...AWG 3/0 ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD |
| Connection Type | I-Line™/Load Lug/Drawout |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 9.73 in H x 2.94 in W x 4.8 in D |
| Enclosure Type | NEMA AB1 |
| EU RoHS Indicator | Y |
| Frame | H |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 3.0000 lb |
| Gross Weight per Pack Metric | 1.36 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 9.8430 in |
| Height [Metric] | 9.8430 cm |
| Item Group | 01112 |
| Length | 37.1480 in |
| Length [Metric] | 37.1480 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=421235&lang=en-us |
| Mounting Type | Plug-In |
| Number Of Poles | 2 |
| Operating Temperature | 40 °C |
| Phase | 1 pH |
| Returnable | Y |
| Standard | IEC-UL LISTED-CE-CSA |
| Sub Brand | POWERPACT |
| Temperature Rating | 104 °F |
| Trip Range | 800 to 1450 A |
| Type | Type HDA |
| UNSPSC | 39121601 |
| UPC 11 | 78590163261 |
| UPC 12 | 785901632610 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 20.6380 in |
| Width [Metric] | 20.6380 cm |
| Wire Size | 14 to 3/0 AWG Al/Cu |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 70 A |
| Interrupt Rating | 18/25/14/20 kA |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 600 VAC/250 VDC |
| PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| I-LINE |
| Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields |
| Flexible and simple offer, with proven performance |
| Direct access to energy metering and energy efficiency |
| AC-phase connection |
| 18 kA at 480 VAC, 25 kA at 240 VAC, 14 kA at 600 VAC, 20 kA at 250 VDC interrupt rating |
