Square D™ EJB34080SA Type EJB Circuit Breaker, 480Y/277 VAC, 80 A, 100 kA at 240 VAC/65 kA at 480Y/277 VAC Interrupt
Custom_Product_Images_Illustration
Square D™ EJB34080SA Type EJB Circuit Breaker, 480Y/277 VAC, 80 A, 100 kA at 240 VAC/65 kA at 480Y/277 VAC Interrupt
SKU795417
MFGR #EJB34080SA
Your Cost: $3,656.77/ea
Square D EJB34080SA MINIATURE CIRCUIT BREAKER 480Y/277V 80A,3-Pole,65kA,80A,Bolt-On,E-Frame,Molded Case Circuit Breaker,Provides overload and short circuit protection,UL Listed - CSA Certified
Square D EJB34080SA MINIATURE CIRCUIT BREAKER 480Y/277V 80A,3-Pole,65kA,80A,Bolt-On,E-Frame,Molded Case Circuit Breaker,Provides overload and short circuit protection,UL Listed - CSA Certified
Alternate Catalog Number EJB34080SA Application HACR rated; NF panelboard ARRA Compliant N Buy American Compliant N Catalog Number EJB34080SA Connection AWG 12...AWG 2/0 ALUMINIUM-AWG 14...AWG 2/0 COPPER,LUGS ALUMINIUM Connection Type Lug Country of Origin MX Currency USD Depth 4.05 in Dimensions 5.8 in H x 2.94 in W x 4.05 in D EU RoHS Indicator Y Frame E Frequency Rating 50/60 Hz Gross Weight Per Pack 4.3400 lb Gross Weight per Pack Metric 1.97 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200040 Height 16.0020 in Height [Metric] 16.0020 cm Item Group 00937 Length 25.1460 in Length [Metric] 25.1460 cm Material Thermoset Composite Resin Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=267978455&lang=en-us Mounting Type Bolt-On Number Of Poles 3 Operating Temperature 40 °C Phase 3 pH Returnable N Standard cULus Standards ARRA, Buy American Act, RoHS Compliant, CSA File No. LR92886, Federal Specification W-C-375B/GEN, HACR Rated, NOM 117, cULus Listed, UL 489 File No. E84967, California Provision: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov Sub Brand EJB Substitute Product Catalog Number N150MH Temperature Rating 104 °F Trip Range 1000 to 2300 A Type Type EJB UNSPSC 39121603 UPC 11 78590164910 UPC 12 785901649106 Warranty Description Contractual Warranty:18 months Width 15.7480 in Width [Metric] 15.7480 cm Wire Size 12 to 2/0 AWG Al, 14 to 2/0 AWG Cu Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 80 A Interrupt Rating 100 kA at 240 VAC/65 kA at 480Y/277 VAC Trip Type Shunt/Thermal Magnetic Voltage Rating 480Y/277 VAC HACR rated; NF panelboard TRIP INDICATOR
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | EJB34080SA |
| Application | HACR rated; NF panelboard |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | EJB34080SA |
| Connection | AWG 12...AWG 2/0 ALUMINIUM-AWG 14...AWG 2/0 COPPER,LUGS ALUMINIUM |
| Connection Type | Lug |
| Country of Origin | MX |
| Currency | USD |
| Depth | 4.05 in |
| Dimensions | 5.8 in H x 2.94 in W x 4.05 in D |
| EU RoHS Indicator | Y |
| Frame | E |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 4.3400 lb |
| Gross Weight per Pack Metric | 1.97 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200040 |
| Height | 16.0020 in |
| Height [Metric] | 16.0020 cm |
| Item Group | 00937 |
| Length | 25.1460 in |
| Length [Metric] | 25.1460 cm |
| Material | Thermoset Composite Resin |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=267978455&lang=en-us |
| Mounting Type | Bolt-On |
| Number Of Poles | 3 |
| Operating Temperature | 40 °C |
| Phase | 3 pH |
| Returnable | N |
| Standard | cULus |
| Standards | ARRA, Buy American Act, RoHS Compliant, CSA File No. LR92886, Federal Specification W-C-375B/GEN, HACR Rated, NOM 117, cULus Listed, UL 489 File No. E84967, California Provision: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Sub Brand | EJB |
| Substitute Product Catalog Number | N150MH |
| Temperature Rating | 104 °F |
| Trip Range | 1000 to 2300 A |
| Type | Type EJB |
| UNSPSC | 39121603 |
| UPC 11 | 78590164910 |
| UPC 12 | 785901649106 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 15.7480 in |
| Width [Metric] | 15.7480 cm |
| Wire Size | 12 to 2/0 AWG Al, 14 to 2/0 AWG Cu |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 80 A |
| Interrupt Rating | 100 kA at 240 VAC/65 kA at 480Y/277 VAC |
| Trip Type | Shunt/Thermal Magnetic |
| Voltage Rating | 480Y/277 VAC |
| HACR rated; NF panelboard |
| TRIP INDICATOR |
