Square D™ 9001K2L1Y PUSHBUTTON OPERATOR 3
SKUPDW~6440676
MFGR #9001K2L1Y
Your Cost: $160.28/ea
Schneider Electric,PUSHBUTTON OPERATOR 30MM TYPE K +OPTIONS,30 mm,BA 9s,Harmony 9001K,chromium plated metal,complete illuminated push-button,complete illuminated push-button,spring return
Schneider Electric,PUSHBUTTON OPERATOR 30MM TYPE K +OPTIONS,30 mm,BA 9s,Harmony 9001K,chromium plated metal,complete illuminated push-button,complete illuminated push-button,spring return
Action SPRING RETURN Actuator SPRING RETURN,YELLOW PROJECTING, UNMARKED ARRA Compliant N Bezel|Housing Polished Chrome Metal Brand Square D™ Buy American Compliant N Catalog Number 9001K2L1Y Color Yellow Contact Configuration SPDT Contact Mode Momentary Country of Origin MX Enclosure NEMA 1-NEMA 12-NEMA 13-NEMA 2-NEMA 3-NEMA 3R-NEMA 4 Enclosure Type NEMA 1/2/3/3R/4/12/13/IP65 EU RoHS Indicator Y Gross Weight Per Pack 0.5000 lb Harmonization Tariff Schedule Code 8531809026 Indicator BA 9S Item Group 21426 Lamp Type BA9S Incandescent Manufacturer Schneider Electric Operating Temperature -25-70 A°C Operator Type Spring Return Returnable Y Series 9001K Size 30 mm Standard 50 GN IEC 60068-2-27,7 GN 2-500 HZ)IEC 60068-2-6,IP66 IEC 60529,JIS C 4520-EN/IEC 60947-5-1-JIS C 852-EN/IEC 60947-5-4-EN/IEC 60947-1-UL 508-CSA C22.2 NO 14,UL 508-NEMA Stock Status NONSTOCK Sub Brand 9001K Substitute Product Catalog Number 9001KA1 Temperature Rating -13 to 158 °F Type Type K Heavy Duty Round Transformer Unmarked UNSPSC 39122216 UPC 11 78590102801 UPC 12 785901028017 CHROMIUM PLATED METAL,COMPLETE ILLUMINATED PUSH-BUTTON This Schneider electric Harmony™ 9001K modular illuminated projecting yellow pushbutton has a chromium plated metal bezel It is supplied with a 110 VAC transformer and fits in a 30 mm hole Without guard
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Action | SPRING RETURN |
| Actuator | SPRING RETURN,YELLOW PROJECTING, UNMARKED |
| ARRA Compliant | N |
| Bezel|Housing | Polished Chrome Metal |
| Brand | Square D™ |
| Buy American Compliant | N |
| Catalog Number | 9001K2L1Y |
| Color | Yellow |
| Contact Configuration | SPDT |
| Contact Mode | Momentary |
| Country of Origin | MX |
| Enclosure | NEMA 1-NEMA 12-NEMA 13-NEMA 2-NEMA 3-NEMA 3R-NEMA 4 |
| Enclosure Type | NEMA 1/2/3/3R/4/12/13/IP65 |
| EU RoHS Indicator | Y |
| Gross Weight Per Pack | 0.5000 lb |
| Harmonization Tariff Schedule Code | 8531809026 |
| Indicator | BA 9S |
| Item Group | 21426 |
| Lamp Type | BA9S Incandescent |
| Manufacturer | Schneider Electric |
| Operating Temperature | -25-70 A°C |
| Operator Type | Spring Return |
| Returnable | Y |
| Series | 9001K |
| Size | 30 mm |
| Standard | 50 GN IEC 60068-2-27,7 GN 2-500 HZ)IEC 60068-2-6,IP66 IEC 60529,JIS C 4520-EN/IEC 60947-5-1-JIS C 852-EN/IEC 60947-5-4-EN/IEC 60947-1-UL 508-CSA C22.2 NO 14,UL 508-NEMA |
| Stock Status | NONSTOCK |
| Sub Brand | 9001K |
| Substitute Product Catalog Number | 9001KA1 |
| Temperature Rating | -13 to 158 °F |
| Type | Type K Heavy Duty Round Transformer Unmarked |
| UNSPSC | 39122216 |
| UPC 11 | 78590102801 |
| UPC 12 | 785901028017 |
| CHROMIUM PLATED METAL,COMPLETE ILLUMINATED PUSH-BUTTON |
| This Schneider electric Harmony™ 9001K modular illuminated projecting yellow pushbutton has a chromium plated metal bezel |
| It is supplied with a 110 VAC transformer and fits in a 30 mm hole |
| Without guard |
