Southwire® 517910508 Type TFN Fixture Wire, 600 VAC, (1) 18 AWG Bare Solid Copper Conductor, 500 ft Reel L

19870 MFG #: 51791-05-08
Coleman Cable
90.69000 / ea
Southwire® Fixture Wire, Type TFN, 600 VAC, 1 Conductor, Bare Solid Copper Conductor, 18 AWG Conductor, 78 mil Outside Dia, 500 ft Reel Length, 1 Strands, Thermoplastic Insulation, Nylon, Black, 90/105 deg C
  • Features
Southwire type TFN conductors may be used as fixture wire and as permitted for fire protective signal circuits as specified in the National Electrical Code® at conductor temperatures not to exceed 90 deg C or 105 deg C when used as AWM
Voltage rating for all applications is 600 volts
15 mil insulation thickness
4 mil jacket thickness
Thermoplastic insulation/nylon sheath heat, moisture, oil, and gasoline resistant
Reel packaging
Heat, moisture, oil and gasoline resistant
-Number of Conductors 1
-Jacket Color Black
-Insulation Material PVC/Nylon
-Stranding Solid
-Outer Diameter 0.082 Inch
-Temperature Rating -20 to 90 Deg C
-Length 500 Ft
-Package Type Reel
-Approval UL 66, UL, CSA C22.2
-ROHS Compliant
-Insulation Thickness 0.016 Inch
-Nylon Insulation Thickness 0.005 Inch
-Application Fixture Wire, Light Fixture, Equipment and Lead Wire
