SolaHD Islatrol™ IE Series Active Tracking Filter, 5 A, 120 VAC
Custom_Product_Images_Illustration
SolaHD Islatrol™ IE Series Active Tracking Filter, 5 A, 120 VAC
SKU326542
MFGR #IE105
Your Cost: $296.44/ea
List: The Islatrol® IE is a series connected DIN or flange mounted high frequency noise filter and surge suppressor. Its Ideal applications include critical industrial loads drawing up to 20 Amps of continuous current, while typical applications include any microprocessor-based products, including industrial PLCs, OEM applications, and motion control systems.
The Islatrol® IE is a series connected DIN or flange mounted high frequency noise filter and surge suppressor. Its Ideal applications include critical industrial loads drawing up to 20 Amps of continuous current, while typical applications include any microprocessor-based products, including industrial PLCs, OEM applications, and motion control systems.
Amperage Rating 3 A Application Critical industrial loads drawing up to 20 Amps of continuous current, microprocessor-based products, including industrial PLCs, OEM applications, and motion control systems. ARRA Compliant N Buy American Compliant N Catalog Number IE105 Class Category A Ringwave (6kv, 200 A, 100 kHz) Connection IEC 998 approved terminals Country of Origin MX Currency USD Dimensions 4.06 in L x 3.06 in W x 3.83 in H Environmental Conditions -40 to 45 deg C Operating, 0 to 95% Humidity EU RoHS Indicator Y Frequency Rating 47-63 Hz Gross Weight Per Pack 0.9500 lb Gross Weight per Pack Metric 0.43 Gross Weight UOM Metric kg Height 3.20 in Height [Metric] 8.1280 cm Indicator Type LED Length 7.30 in Length [Metric] 18.5420 cm Modes of Protection L-N/L-G/N-G Mounting DIN/Flange Mounting Type DIN/Flange Operating Temperature -40 DEG C to +45 DEG C at Full Load; Derate Linearly to 60% at +70 DEG C Peak Surge Current 45000 A Phase 1 Response Time <0.5 ns Normal Mode/< 5 ns Common Mode Series IE Series Short Circuit Rating Surge current capacity - 45,000 Amps Size 4.06 Length x 3.06 Width x 3.83 High IN in Standard ANSI/UL 1449 Third Edition Type 4,1283, CUL recognized, CE, ROHS Standards ANSI/UL 1449 3rd Edition Type 4, 1283, cUL Listed, CE Certified, RoHS Compliant Sub Brand Edco Type Islatrol IE Series Type Of Indicators LED Power Indicators UNSPSC 39121610 UPC 11 63391407427 UPC 12 633914074272 Voltage Rating 120 V Width 6.00 in Width [Metric] 15.2400 cm Stock Status NONSTOCK Brand SolaHD™ Manufacturer Emerson Bandwidth 100 kHz to 50 MHz Electrical Ratings 3 A at 120 VAC Material Plastic Number of Wires 2 Critical industrial loads drawing up to 20 Amps of continuous current, microprocessor-based products, including industrial PLCs, OEM applications, and motion control systems. Surge current capacity 45,000 Amps; Transient protection in all modes: line to neutral, line to ground, and neutral to ground; LED status indication and form C contact for remote indication; DIN mountable enclosure -40 to 45 deg C operating temperature at full load, Derate Linearly to 60 % at 70 deg C 47 - 63 Hz frequency Category A Ringwave (6 kV, 200 A, 100 kHz) Multi-staged design, combining a unique hybrid clamping network with the active tracking technology of the Islatrol® family Surge current capacity 45000 Amp Transient protection in all modes: line to neutral, line to ground and neutral to ground LED status indication and form C contact for remote indication <0.5 ns Normal mode and <5 ns common mode response time Peak surge current capability for line to neutral is 15000 A, line to ground is 15000 A and neutral to ground is 15000 A, total is 45000 A DIN/Flange mounting
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Amperage Rating | 3 A |
| Application | Critical industrial loads drawing up to 20 Amps of continuous current, microprocessor-based products, including industrial PLCs, OEM applications, and motion control systems. |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | IE105 |
| Class | Category A Ringwave (6kv, 200 A, 100 kHz) |
| Connection | IEC 998 approved terminals |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 4.06 in L x 3.06 in W x 3.83 in H |
| Environmental Conditions | -40 to 45 deg C Operating, 0 to 95% Humidity |
| EU RoHS Indicator | Y |
| Frequency Rating | 47-63 Hz |
| Gross Weight Per Pack | 0.9500 lb |
| Gross Weight per Pack Metric | 0.43 |
| Gross Weight UOM Metric | kg |
| Height | 3.20 in |
| Height [Metric] | 8.1280 cm |
| Indicator Type | LED |
| Length | 7.30 in |
| Length [Metric] | 18.5420 cm |
| Modes of Protection | L-N/L-G/N-G |
| Mounting | DIN/Flange |
| Mounting Type | DIN/Flange |
| Operating Temperature | -40 DEG C to +45 DEG C at Full Load; Derate Linearly to 60% at +70 DEG C |
| Peak Surge Current | 45000 A |
| Phase | 1 |
| Response Time | <0.5 ns Normal Mode/< 5 ns Common Mode |
| Series | IE Series |
| Short Circuit Rating | Surge current capacity - 45,000 Amps |
| Size | 4.06 Length x 3.06 Width x 3.83 High IN in |
| Standard | ANSI/UL 1449 Third Edition Type 4,1283, CUL recognized, CE, ROHS |
| Standards | ANSI/UL 1449 3rd Edition Type 4, 1283, cUL Listed, CE Certified, RoHS Compliant |
| Sub Brand | Edco |
| Type | Islatrol IE Series |
| Type Of Indicators | LED Power Indicators |
| UNSPSC | 39121610 |
| UPC 11 | 63391407427 |
| UPC 12 | 633914074272 |
| Voltage Rating | 120 V |
| Width | 6.00 in |
| Width [Metric] | 15.2400 cm |
| Stock Status | NONSTOCK |
| Brand | SolaHD™ |
| Manufacturer | Emerson |
| Bandwidth | 100 kHz to 50 MHz |
| Electrical Ratings | 3 A at 120 VAC |
| Material | Plastic |
| Number of Wires | 2 |
| Critical industrial loads drawing up to 20 Amps of continuous current, microprocessor-based products, including industrial PLCs, OEM applications, and motion control systems. |
| Surge current capacity 45,000 Amps; Transient protection in all modes: line to neutral, line to ground, and neutral to ground; LED status indication and form C contact for remote indication; DIN mountable enclosure |
| -40 to 45 deg C operating temperature at full load, Derate Linearly to 60 % at 70 deg C |
| 47 - 63 Hz frequency |
| Category A Ringwave (6 kV, 200 A, 100 kHz) |
| Multi-staged design, combining a unique hybrid clamping network with the active tracking technology of the Islatrol® family |
| Surge current capacity 45000 Amp |
| Transient protection in all modes: line to neutral, line to ground and neutral to ground |
| LED status indication and form C contact for remote indication |
| <0.5 ns Normal mode and <5 ns common mode response time |
| Peak surge current capability for line to neutral is 15000 A, line to ground is 15000 A and neutral to ground is 15000 A, total is 45000 A |
| DIN/Flange mounting |
