SolaHD™
SolaHD HS14F1BS Non-Ventilated Automation Transformer, 208/240/415/480 VAC Primary, 120/240 VAC Secondary, 1 kVA, 60 Hz
Custom_Product_Images_Illustration
SolaHD™
SolaHD HS14F1BS Non-Ventilated Automation Transformer, 208/240/415/480 VAC Primary, 120/240 VAC Secondary, 1 kVA, 60 Hz
SKU89931
MFGR #HS14F1BS
Your Cost: $550.48/ea
List: SolaHD encapsulated transformers are rated for Hazardous Locations as well as harsh industrial environments. Encapsulation and rugged UL Listed/NEMA Type 3R enclosures protect the transformer from dust, moisture and provide extra shock and vibration resistance. SolaHD transformers fully comply with the latest addition of the National Electrical Code for Class I, Division 2, Group A, B, C and D locations when installed in compliance with NEC 501.100 (B).
SolaHD encapsulated transformers are rated for Hazardous Locations as well as harsh industrial environments. Encapsulation and rugged UL Listed/NEMA Type 3R enclosures protect the transformer from dust, moisture and provide extra shock and vibration resistance. SolaHD transformers fully comply with the latest addition of the National Electrical Code for Class I, Division 2, Group A, B, C and D locations when installed in compliance with NEC 501.100 (B).
Application SolaHD encapsulated transformer rated for harsh industrial environments ARRA Compliant Y Buy American Compliant Y Catalog Number HS14F1BS Country of Origin US Currency USD Enclosure NEMA 3R, Class 1 Div 2 Group A,B,C and D EU RoHS Indicator Y Gross Weight Per Pack 32.8000 lb Gross Weight per Pack Metric 14.88 Gross Weight UOM Metric kg Height 6.30 in Height [Metric] 16.0020 cm Input Voltage 600 Volts Primary VAC KVA Rating 1 VAC Length 6.80 in Length [Metric] 17.2720 cm Maximum Input Current 1.67 A Maximum Output Current 4.17/8.33 A Number Of Phases 1 Output Voltage 120/240 Volt Secondary Hz Standard cULus Listed: E25872, E77014, UL 1561 or UL 506, CSA C22.2 No. 47 or No. 66 Standards cULus E25872, E77014, UL 1561 or UL 506, CSA C22.2 No. 47 or No. 66, RoHS Compliant Temperature Rating 115 DEG C Temperature Rise Under Full Load IN Type Automation Transformers - Non-Ventilated 50 VA to 45 kVA UNSPSC 39121027 UPC 11 78347210084 UPC 12 783472100842 Wattage 1,000 W Width 11.20 in Width [Metric] 28.4480 cm Stock Status NONSTOCK Brand SolaHD™ Manufacturer Emerson Frequency Rating 60 Hz SolaHD encapsulated transformer rated for harsh industrial environments UL Listed/NEMA Type 3R encapsulated enclosure for indoor and outdoor service; Electrostatically shielded for quality power on sizes 1 kVA and larger; Copper lead wire terminations; .500 - 45 kVA units are capsulated with electrical grade silica and epoxy for industrial applications. Rolled steel enclosure. Conduit knockouts for side entry into wiring compartment NEMA type 3R non encapsulated enclosure for indoor and outdoor service 80 deg C temperature rise under full load Copper wound designs UL Listed/NEMA Type 3R encapsulated enclosure for indoor and outdoor service 190/200/208/220/380/400/415/440, 200/208/230/400/415/460, 208/240/415/480 VAC primary volt 110/220, 115/230, 120/240 VAC secondary volt 1.04/0.512 A primary, 2.08/1.04 A secondary
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Application | SolaHD encapsulated transformer rated for harsh industrial environments |
| ARRA Compliant | Y |
| Buy American Compliant | Y |
| Catalog Number | HS14F1BS |
| Country of Origin | US |
| Currency | USD |
| Enclosure | NEMA 3R, Class 1 Div 2 Group A,B,C and D |
| EU RoHS Indicator | Y |
| Gross Weight Per Pack | 32.8000 lb |
| Gross Weight per Pack Metric | 14.88 |
| Gross Weight UOM Metric | kg |
| Height | 6.30 in |
| Height [Metric] | 16.0020 cm |
| Input Voltage | 600 Volts Primary VAC |
| KVA Rating | 1 VAC |
| Length | 6.80 in |
| Length [Metric] | 17.2720 cm |
| Maximum Input Current | 1.67 A |
| Maximum Output Current | 4.17/8.33 A |
| Number Of Phases | 1 |
| Output Voltage | 120/240 Volt Secondary Hz |
| Standard | cULus Listed: E25872, E77014, UL 1561 or UL 506, CSA C22.2 No. 47 or No. 66 |
| Standards | cULus E25872, E77014, UL 1561 or UL 506, CSA C22.2 No. 47 or No. 66, RoHS Compliant |
| Temperature Rating | 115 DEG C Temperature Rise Under Full Load IN |
| Type | Automation Transformers - Non-Ventilated 50 VA to 45 kVA |
| UNSPSC | 39121027 |
| UPC 11 | 78347210084 |
| UPC 12 | 783472100842 |
| Wattage | 1,000 W |
| Width | 11.20 in |
| Width [Metric] | 28.4480 cm |
| Stock Status | NONSTOCK |
| Brand | SolaHD™ |
| Manufacturer | Emerson |
| Frequency Rating | 60 Hz |
| SolaHD encapsulated transformer rated for harsh industrial environments |
| UL Listed/NEMA Type 3R encapsulated enclosure for indoor and outdoor service; Electrostatically shielded for quality power on sizes 1 kVA and larger; Copper lead wire terminations; .500 - 45 kVA units are capsulated with electrical grade silica and epoxy for industrial applications. Rolled steel enclosure. |
| Conduit knockouts for side entry into wiring compartment |
| NEMA type 3R non encapsulated enclosure for indoor and outdoor service |
| 80 deg C temperature rise under full load |
| Copper wound designs |
| UL Listed/NEMA Type 3R encapsulated enclosure for indoor and outdoor service |
| 190/200/208/220/380/400/415/440, 200/208/230/400/415/460, 208/240/415/480 VAC primary volt |
| 110/220, 115/230, 120/240 VAC secondary volt |
| 1.04/0.512 A primary, 2.08/1.04 A secondary |
