SolaHD HS1 Encapsulated Buck Boost Transformer, 120/240 VAC Primary, 12/24 VAC Secondary, 0.5 kVA, 60 Hz, 1 Phase
Custom_Product_Images_Illustration
SolaHD HS1 Encapsulated Buck Boost Transformer, 120/240 VAC Primary, 12/24 VAC Secondary, 0.5 kVA, 60 Hz, 1 Phase
SKU89926
MFGR #HS19F500B
Your Cost: $311.36/ea
List: Buck-Boost transformers are small, single phase, dry type distribution transformers designed and shipped as insulating/isolating transformers. They have a dual voltage primary and a dual voltage secondary. These transformers can be connected for a wide range of voltage combinations. The most common use is to buck (lower) or boost (raise) the supply voltage a small amount, usually 5 to 27%. Buck-boost transformers are in compliance with NEC Article 210.9, Exception 1 when field connected as an autotransformer.
Buck-Boost transformers are small, single phase, dry type distribution transformers designed and shipped as insulating/isolating transformers. They have a dual voltage primary and a dual voltage secondary. These transformers can be connected for a wide range of voltage combinations. The most common use is to buck (lower) or boost (raise) the supply voltage a small amount, usually 5 to 27%. Buck-boost transformers are in compliance with NEC Article 210.9, Exception 1 when field connected as an autotransformer.
Application SolaHD encapsulated transformers are rated for hazardous locations and harsh industrial environments. ARRA Compliant Y Boost Voltage 100-120 , 229-240 V Buck Voltage 132-120 , 264-240 Buy American Compliant Y Catalog Number HS19F500B Connection Conduit Knockouts for side entry to wiring compartment Connection Type Lead Wire Country of Origin US Currency USD Design Encapsulated Dimensions 5 in L x 6 in W x 10 in H Enclosure NEMA 3R, Class 1 Div 2 Group A,B,C and D Enclosure Type NEMA 3R EU RoHS Indicator Y Gross Weight Per Pack 21.7000 lb Gross Weight per Pack Metric 9.84 Gross Weight UOM Metric kg Height 6.30 in Height [Metric] 16.0020 cm Length 12.20 in Length [Metric] 30.9880 cm Maximum Amperage Rating 0.833 A Maximum Input Current 0.833 A Maximum Output Current 2.08/4.16 A Number Of Phases 1 Series HS19 Standard cULus Listed: E25872, E77014, UL 1561 or UL 506, CSA C22.2 No. 47 or No. 66 Standards ARRA CompliantBuy American Act CompliantRoHS CompliantUL 506UL 1561CSA C22.2 No. 47CSA C22.2 No. 66cULus File No. E25872cULus File No. E77014Class 1 Div 2 Group A, B, C, D Temperature Rating 115 DEG C Temperature Rise Under Full Load °C Type Buck-Boost Transformer UNSPSC 39121025 UPC 11 78347210062 UPC 12 783472100620 Wattage 500 W Width 6.80 in Width [Metric] 17.2720 cm Stock Status NONSTOCK Brand SolaHD™ Manufacturer Emerson Frequency Rating 60 Hz Phase 1 Power Rating 0.5 kVA Primary Voltage 120 X 240 V Secondary Voltage 12/24 V SolaHD encapsulated transformers are rated for hazardous locations and harsh industrial environments. UL Listed/NEMA Type 3R encapsulated enclosure for indoor and outdoor service; Electrostatically shielded for quality power on sizes 1 kVA and larger; Copper lead wire terminations; .500 - 45 kVA units are capsulated with electrical grade silica and epoxy for industrial applications. Rolled steel enclosure. Compact, lightweight, can be connected as an autotransformer Buck-boost transformers are designed to supply power to low voltage lighting circuits, control panels or other systems requiring 12, 16, 24, 32, or 48 volts They can handle loads up to 20 times the nameplate rating Conduit knockouts for side entry into wiring compartment UL listed/NEMA type 3R encapsulated enclosure for indoor and outdoor service Electrostatically shielded for quality power on sizes 1 kVA and larger 500 to 45 kVA units are capsulated with electrical grade silica and epoxy for industrial applications Rolled steel enclosure
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Application | SolaHD encapsulated transformers are rated for hazardous locations and harsh industrial environments. |
| ARRA Compliant | Y |
| Boost Voltage | 100-120 , 229-240 V |
| Buck Voltage | 132-120 , 264-240 |
| Buy American Compliant | Y |
| Catalog Number | HS19F500B |
| Connection | Conduit Knockouts for side entry to wiring compartment |
| Connection Type | Lead Wire |
| Country of Origin | US |
| Currency | USD |
| Design | Encapsulated |
| Dimensions | 5 in L x 6 in W x 10 in H |
| Enclosure | NEMA 3R, Class 1 Div 2 Group A,B,C and D |
| Enclosure Type | NEMA 3R |
| EU RoHS Indicator | Y |
| Gross Weight Per Pack | 21.7000 lb |
| Gross Weight per Pack Metric | 9.84 |
| Gross Weight UOM Metric | kg |
| Height | 6.30 in |
| Height [Metric] | 16.0020 cm |
| Length | 12.20 in |
| Length [Metric] | 30.9880 cm |
| Maximum Amperage Rating | 0.833 A |
| Maximum Input Current | 0.833 A |
| Maximum Output Current | 2.08/4.16 A |
| Number Of Phases | 1 |
| Series | HS19 |
| Standard | cULus Listed: E25872, E77014, UL 1561 or UL 506, CSA C22.2 No. 47 or No. 66 |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantUL 506UL 1561CSA C22.2 No. 47CSA C22.2 No. 66cULus File No. E25872cULus File No. E77014Class 1 Div 2 Group A, B, C, D |
| Temperature Rating | 115 DEG C Temperature Rise Under Full Load °C |
| Type | Buck-Boost Transformer |
| UNSPSC | 39121025 |
| UPC 11 | 78347210062 |
| UPC 12 | 783472100620 |
| Wattage | 500 W |
| Width | 6.80 in |
| Width [Metric] | 17.2720 cm |
| Stock Status | NONSTOCK |
| Brand | SolaHD™ |
| Manufacturer | Emerson |
| Frequency Rating | 60 Hz |
| Phase | 1 |
| Power Rating | 0.5 kVA |
| Primary Voltage | 120 X 240 V |
| Secondary Voltage | 12/24 V |
| SolaHD encapsulated transformers are rated for hazardous locations and harsh industrial environments. |
| UL Listed/NEMA Type 3R encapsulated enclosure for indoor and outdoor service; Electrostatically shielded for quality power on sizes 1 kVA and larger; Copper lead wire terminations; .500 - 45 kVA units are capsulated with electrical grade silica and epoxy for industrial applications. Rolled steel enclosure. |
| Compact, lightweight, can be connected as an autotransformer |
| Buck-boost transformers are designed to supply power to low voltage lighting circuits, control panels or other systems requiring 12, 16, 24, 32, or 48 volts |
| They can handle loads up to 20 times the nameplate rating |
| Conduit knockouts for side entry into wiring compartment |
| UL listed/NEMA type 3R encapsulated enclosure for indoor and outdoor service |
| Electrostatically shielded for quality power on sizes 1 kVA and larger |
| 500 to 45 kVA units are capsulated with electrical grade silica and epoxy for industrial applications |
| Rolled steel enclosure |
