SolaHD™
SolaHD 83 Series Linear DC Power Supply, 104 to 127/208 to 254 VAC Input, 5 VDC Output, 15 W, 3 A, Panel Mount
Custom_Product_Images_Illustration
SolaHD™
SolaHD 83 Series Linear DC Power Supply, 104 to 127/208 to 254 VAC Input, 5 VDC Output, 15 W, 3 A, Panel Mount
SKU90042
MFGR #83-05-230-3
Your Cost: $126.35/ea
SolaHD DC Power Supply, Linear, Series: 83 Series, 104 to 127/208 to 254 VAC Input, 5 VDC Output, 15 W, 3 A, 50/60 Hz, Panel Mount, 4 in Width, 2-1/2 in Depth, 4-3/4 in Height
SolaHD DC Power Supply, Linear, Series: 83 Series, 104 to 127/208 to 254 VAC Input, 5 VDC Output, 15 W, 3 A, 50/60 Hz, Panel Mount, 4 in Width, 2-1/2 in Depth, 4-3/4 in Height
Catalog Number 83-05-230-3 Country of Origin CN Depth 2-1/2 in Frequency Rating 50/60 Hz Gross Weight Per Pack 6.4000 lb Height 4-3/4 in Series 83 Series Standards UL Recognized, CSA Certified Type Linear UNSPSC 39121004 UPC 11 78347283075 UPC 12 78347283075 Width 4 in Stock Status NONSTOCK Brand SolaHD™ Manufacturer Emerson Amperage Rating 3 A Input Voltage 104 to 127/208 to 254 VAC Mounting Type Panel Output Voltage 5 VDC Power Rating 15 W Low noise output, 115/230 Vac Input, Remote sensing, Designed for both bench and rack use, Current limiting -- automatic reset Low noise output Remote sensing Designed for both bench and rack use Completely protected short circuit proof and automatic foldback Current limiting automatic reset Isolated floating output Built-in OVP on 5 VAC models Terminal block +/-0.1% regulation line and load 0.1% pk pard (ripple and noise) 10 mV rms periodic deviations +/-5% minimum output voltage adjustment Less than 50 msec transient recovery time -40 to 85 deg C storage temperature 0 to 50 deg C operating temperature 0.03% temperature co-efficient May be used positive or negative Protected with automatic recovery short circuit protection 5% maximum allowable lead drop for remote sensing 120% rated maximum output current
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Catalog Number | 83-05-230-3 |
| Country of Origin | CN |
| Depth | 2-1/2 in |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 6.4000 lb |
| Height | 4-3/4 in |
| Series | 83 Series |
| Standards | UL Recognized, CSA Certified |
| Type | Linear |
| UNSPSC | 39121004 |
| UPC 11 | 78347283075 |
| UPC 12 | 78347283075 |
| Width | 4 in |
| Stock Status | NONSTOCK |
| Brand | SolaHD™ |
| Manufacturer | Emerson |
| Amperage Rating | 3 A |
| Input Voltage | 104 to 127/208 to 254 VAC |
| Mounting Type | Panel |
| Output Voltage | 5 VDC |
| Power Rating | 15 W |
| Low noise output, 115/230 Vac Input, Remote sensing, Designed for both bench and rack use, Current limiting -- automatic reset |
| Low noise output |
| Remote sensing |
| Designed for both bench and rack use |
| Completely protected short circuit proof and automatic foldback |
| Current limiting automatic reset |
| Isolated floating output |
| Built-in OVP on 5 VAC models |
| Terminal block |
| +/-0.1% regulation line and load |
| 0.1% pk pard (ripple and noise) |
| 10 mV rms periodic deviations |
| +/-5% minimum output voltage adjustment |
| Less than 50 msec transient recovery time |
| -40 to 85 deg C storage temperature |
| 0 to 50 deg C operating temperature |
| 0.03% temperature co-efficient |
| May be used positive or negative |
| Protected with automatic recovery short circuit protection |
| 5% maximum allowable lead drop for remote sensing |
| 120% rated maximum output current |
