Siemens
Siemens Speedfax™ VL NJG3B300L Molded Case Circuit Breaker With Lug, 600 VAC, 250 A, 35 kA Interrupt, 3 Poles
Siemens
Siemens Speedfax™ VL NJG3B300L Molded Case Circuit Breaker With Lug, 600 VAC, 250 A, 35 kA Interrupt, 3 Poles
SKU479602
MFGR #NJG3B300L
Your Cost: $17,113.71/ea
List: Siemens NJG3B300L 3P 300A 35KA CB
Siemens NJG3B300L 3P 300A 35KA CB
Actuator Type Handle Alternate Catalog Number US2:NJG3B300L Application GLOBAL INTERCHANGEABLE ARRA Compliant C Buy American Compliant C Catalog Number NJG3B300L Connection LINE & LOAD STANDARD (CU/AL) LUGS Connection Type Line/Load Lug Country of Origin DE Currency USD Dimensions 11 in H x 5.5 in W x 4.2 in D EU RoHS Indicator C Frame JG/400A Frequency Rating 50/60 Hz Gross Weight Per Pack 0.0100 lb Gross Weight per Pack Metric 0.00 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 0 Length 0 Material MOLDED CASE CIRCUIT BREAKER Number Of Poles 3 Operating Temperature 40 °C Phase 3 pH Returnable N Standard UL/IEC/CE/CSA/NOM/CCC Standards ARRA CompliantBuy American Act CompliantRoHS CompliantUL ListedCE CertifiedCSA CertifiedIEC Certified Sub Brand VL Temperature Rating 40 °C Type Low Voltage UNSPSC 39121601 UPC 11 78364358583 UPC 12 783643585836 Width 0 Stock Status NONSTOCK Brand Siemens Manufacturer Siemens Amperage Rating 250 A Interrupt Rating 35 kA Trip Type Thermal Magnetic Voltage Rating 600 VAC GLOBAL INTERCHANGEABLE Modular design - The modularity of the VL allows for last minute adaptation, forgives changes in system design and reduces inventory. Just two families of common internal accessories cover the complete range of VL breakers. The accessories are field installable and conveniently located in isolated pockets behind the front cover. No special tools are required Compact size - Reduced dimensions save panel space, which can reduce the overall system design requirements and therefore material costs Global ratings - VL breakers are designed for global use, allowing the user to serve virtually every market using one design and footprint Communication capable - Communication is possible over PROFIBUS DP or MODBUS RTU with electronic trip units Breadth of offering - A wide variety of protection options, ampere ratings as well as a full basket of available accessories ensure that Siemens has the product to suit your needs. Most VL breakers are also available with 100% ratings High reliability - Most VL components are tested to twice the endurance specified by UL global interchangeable Without auxiliary/alarm switch
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator Type | Handle |
| Alternate Catalog Number | US2:NJG3B300L |
| Application | GLOBAL INTERCHANGEABLE |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | NJG3B300L |
| Connection | LINE & LOAD STANDARD (CU/AL) LUGS |
| Connection Type | Line/Load Lug |
| Country of Origin | DE |
| Currency | USD |
| Dimensions | 11 in H x 5.5 in W x 4.2 in D |
| EU RoHS Indicator | C |
| Frame | JG/400A |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 0.0100 lb |
| Gross Weight per Pack Metric | 0.00 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 0 |
| Length | 0 |
| Material | MOLDED CASE CIRCUIT BREAKER |
| Number Of Poles | 3 |
| Operating Temperature | 40 °C |
| Phase | 3 pH |
| Returnable | N |
| Standard | UL/IEC/CE/CSA/NOM/CCC |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantUL ListedCE CertifiedCSA CertifiedIEC Certified |
| Sub Brand | VL |
| Temperature Rating | 40 °C |
| Type | Low Voltage |
| UNSPSC | 39121601 |
| UPC 11 | 78364358583 |
| UPC 12 | 783643585836 |
| Width | 0 |
| Stock Status | NONSTOCK |
| Brand | Siemens |
| Manufacturer | Siemens |
| Amperage Rating | 250 A |
| Interrupt Rating | 35 kA |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 600 VAC |
| GLOBAL INTERCHANGEABLE |
| Modular design - The modularity of the VL allows for last minute adaptation, forgives changes in system design and reduces inventory. Just two families of common internal accessories cover the complete range of VL breakers. The accessories are field installable and conveniently located in isolated pockets behind the front cover. No special tools are required |
| Compact size - Reduced dimensions save panel space, which can reduce the overall system design requirements and therefore material costs |
| Global ratings - VL breakers are designed for global use, allowing the user to serve virtually every market using one design and footprint |
| Communication capable - Communication is possible over PROFIBUS DP or MODBUS RTU with electronic trip units |
| Breadth of offering - A wide variety of protection options, ampere ratings as well as a full basket of available accessories ensure that Siemens has the product to suit your needs. Most VL breakers are also available with 100% ratings |
| High reliability - Most VL components are tested to twice the endurance specified by UL |
| global interchangeable |
| Without auxiliary/alarm switch |
