Siemens Speedfax™ VL HEM3M050L Molded Case Circuit Breaker, 480 VAC, 50 A, 65 kA Interrupt, 3 Poles, Magnetic Trip
Molded Case Circuit Breakers
810358
MFG #: HEM3M050L
Siemens
5786.61000
/ ea
Siemens Speedfax™ VL Molded Case Circuit Breaker, 480 VAC, 50 A, 50/60 Hz, 65 kA Interrupt, EG/125 A Frame, Magnetic Trip, 150 to 550 A Trip, 3 Poles, 3-Phase, Line/Load Lug, 14 to 3/0 AWG Wire, 40 deg C, 7 in L x 5 in W x 5 in H
- Catalog 1 URL - Siemens_HHED63B015A_Catalog.pdf(Catalog 1 URL)
- Catalog URL - Siemens_HHED63B015A_Catalog.pdf(Catalog URL)
- Computer~Aided [CAD|BIM] Model URL - SIE_DW_EG-3Pole-4Pole-Breaker-Frame.dwg(Computer~Aided [CAD|BIM] Model URL)
- http://www.sea.siemens.com(Seller Home Page URL)
- Spec Sheet 1 URL - ID-SPE-v2-Siemens-Molded-Case-Circuit-Breakers-GenApp_HEM_Cut_Sheet.pdf(Spec Sheet 1 URL)
- Spec Sheet URL - Siemens-Molded-Case-Circuit-Breakers-GenApp_HEM_Cut_Sheet.pdf(Spec Sheet URL)
- User Manual URL - SIE_IS_EG_Motor-Protector.pdf(User Manual URL)
- Applications
- Features
| MOTOR CIRCUIT PROTECTOR |
| Molded case circuit breakers are used in motor circuits as a disconnecting means and for short circuit protection |
| They should be used in conjunction with motor running, over-current-protection devices and should permit the motor to start without nuisance tripping from motor-inrush current |
| The circuit breaker should have a continuous current rating of not less than 115% of the motor full load current |
| 14 to 3/0 AWG copper wire range |
| 150 to 550 A instantaneous trip |
| 65 kA at 480 VAC interrupt rating |
