Siemens Speedfax™ VL HEM3M030L Molded Case Circuit Breaker, 480 VAC, 30 A, 65 kA Interrupt, 3 Poles, Magnetic Trip
Molded Case Circuit Breakers
465615
MFG #: HEM3M030L
Siemens
5786.61000
/ ea
Siemens Speedfax™ VL Molded Case Circuit Breaker, 480 VAC, 30 A, 50/60 Hz, 65 kA Interrupt, EG/125 A Frame, Magnetic Trip, 90 to 330 A Trip, 3 Poles, 3-Phase, Line/Load Lug, 14 to 3/0 AWG Wire, 40 deg C, 7 in L x 5 in W x 5 in H
- Computer~Aided [CAD|BIM] Model URL - SIE_DW_EG-3Pole-4Pole-Breaker-Frame.dwg(Computer~Aided [CAD|BIM] Model URL)
- http://www.sea.siemens.com(WEB SELLER HOME PAGE URL)
- User Manual URL - SIE_IS_EG_Motor-Protector.pdf(User Manual URL)
- WEB CATALOG 1 URL - Siemens_HHED63B015A_Catalog.pdf(WEB CATALOG 1 URL)
- WEB CATALOG URL - Siemens_HHED63B015A_Catalog.pdf(WEB CATALOG URL)
- WEB SPEC SHEET URL - SF17-07-072.pdf(WEB SPEC SHEET URL)
- Applications
- Features
| MOTOR CIRCUIT PROTECTOR |
| Molded case circuit breakers are used in motor circuits as a disconnecting means and for short circuit protection |
| They should be used in conjunction with motor running, over-current-protection devices and should permit the motor to start without nuisance tripping from motor-inrush current |
| The circuit breaker should have a continuous current rating of not less than 115% of the motor full load current |
| 14 to 3/0 AWG copper wire range |
| 65 kA at 480 VAC interrupt rating |
| 65 kA at 480 VAC interrupt rating |
