Siemens Speedfax™ VL HEB3B080B Molded Case Circuit Breaker, 480 VAC, 80 A, 65 kA Interrupt, 3 Poles
Molded Case Circuit Breakers
820722
MFG #: HEB3B080B
Siemens
7509.02000
/ ea
Siemens Speedfax™ VL Molded Case Circuit Breaker, 480 VAC, 80 A, 50/60 Hz, 65 kA Interrupt, HEB/125 A Frame, Thermal Magnetic Trip, 3 Poles, 3-Phase, Load Lug, 14 to 1/0 AWG Wire, Panel Mount, 40 deg C, 6.8 in L x 3.8 in W x 4 in H
- Computer~Aided [CAD|BIM] Model URL - SIE_DW_EB-1Pole-2Pole-3Pole-Breaker.dwg(Computer~Aided [CAD|BIM] Model URL)
- http://www.sea.siemens.com(Seller Home Page URL)
- Spec Sheet URL - DatasheetService?format=PDF&caller=EGH&mlfbs=US2:HEB3B080B&language=en(Spec Sheet URL)
- Spec Sheet URL - DatasheetService?format=PDF&caller=PDPS&mlfbs=US2:HEB3B080B&language=en(Spec Sheet URL)
- Spec Sheet URL - sf-11-sect-07-029-036.pdf(Spec Sheet URL)
- User Manual URL - man(User Manual URL)
- User Manual URL - SIE_IS_EB-Fr_Mounting-Instructions.pdf(User Manual URL)
- Features
| PANELBOARD MOUNTING |
| Load end standard copper aluminum lugs |
| Long time and instantaneous trip functions |
| Global interchangeable |
