Siemens Speedfax™ HQR22B150 Low Voltage Molded Case Circuit Breaker, 240 VAC, 150 A, 65 kA Interrupt, 2 Poles
Custom_Product_Images_Illustration
Siemens Speedfax™ HQR22B150 Low Voltage Molded Case Circuit Breaker, 240 VAC, 150 A, 65 kA Interrupt, 2 Poles
SKU991836
MFGR #HQR22B150
Your Cost: $1,105.44/ea
List: Siemens Speedfax™ Molded Case Circuit Breaker, Low Voltage, 240 VAC, 150 A, 50/60 Hz, 65 kA Interrupt, QR Frame, Thermal Magnetic Trip, 2 Poles, Load Lug, 3 AWG to 300 kcmil Cu/6 AWG to 350 kcmil Al/Cu Wire, NEMA 1/3R, 40 deg C, 7 in H x 3 in W x 2.53 in D
Siemens Speedfax™ Molded Case Circuit Breaker, Low Voltage, 240 VAC, 150 A, 50/60 Hz, 65 kA Interrupt, QR Frame, Thermal Magnetic Trip, 2 Poles, Load Lug, 3 AWG to 300 kcmil Cu/6 AWG to 350 kcmil Al/Cu Wire, NEMA 1/3R, 40 deg C, 7 in H x 3 in W x 2.53 in D
Alternate Catalog Number US2:HQR22B150 Application Circuit Protection ARRA Compliant C Buy American Compliant C Catalog Number HQR22B150 Country of Origin MX Currency USD EU RoHS Indicator C Gross Volume Per Pack 173.85 Gross Volume UOM in Gross Weight Per Pack 3.2000 lb Gross Weight per Pack Metric 1.45 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 4.5000 in Height [Metric] 11.4300 cm Length 7.6500 in Length [Metric] 19.4310 cm Number Of Poles 2 Returnable Y Standard UL489/CSA-C22.2/NOM-003 Standards UL 489, HACR Rated UNSPSC 39121601 UPC 11 80476613634 UPC 12 804766136344 Width 5.0500 in Width [Metric] 12.8270 cm Stock Status NONSTOCK Brand Siemens Manufacturer Siemens Amperage Rating 150 A Voltage Rating 240 V Circuit Protection QR 250A 240V Breakers
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | US2:HQR22B150 |
| Application | Circuit Protection |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | HQR22B150 |
| Country of Origin | MX |
| Currency | USD |
| EU RoHS Indicator | C |
| Gross Volume Per Pack | 173.85 |
| Gross Volume UOM | in |
| Gross Weight Per Pack | 3.2000 lb |
| Gross Weight per Pack Metric | 1.45 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 4.5000 in |
| Height [Metric] | 11.4300 cm |
| Length | 7.6500 in |
| Length [Metric] | 19.4310 cm |
| Number Of Poles | 2 |
| Returnable | Y |
| Standard | UL489/CSA-C22.2/NOM-003 |
| Standards | UL 489, HACR Rated |
| UNSPSC | 39121601 |
| UPC 11 | 80476613634 |
| UPC 12 | 804766136344 |
| Width | 5.0500 in |
| Width [Metric] | 12.8270 cm |
| Stock Status | NONSTOCK |
| Brand | Siemens |
| Manufacturer | Siemens |
| Amperage Rating | 150 A |
| Voltage Rating | 240 V |
| Circuit Protection |
| QR 250A 240V Breakers |
