Siemens Speedfax™ HGG3B040L Low Voltage Molded Case Circuit Breaker, 480 VAC, 40 A, 35 kA Interrupt, 3 Poles
Custom_Product_Images_Illustration
Siemens Speedfax™ HGG3B040L Low Voltage Molded Case Circuit Breaker, 480 VAC, 40 A, 35 kA Interrupt, 3 Poles
SKU893263
MFGR #HGG3B040L
Your Cost: $1,212.68/ea
List: Siemens Speedfax™ Molded Case Circuit Breaker, Low Voltage, 480 VAC, 40 A, 50/60 Hz, 35 kA Interrupt, HGG Frame, Thermal Magnetic Trip, 3 Poles, 3-Phase, Cable In/Out/Line/Load Lug, 8 to 1/0 AWG Al/Cu Wire, 40 deg C, 5.4 in H x 3 in W x 2.8 in D
Siemens Speedfax™ Molded Case Circuit Breaker, Low Voltage, 480 VAC, 40 A, 50/60 Hz, 35 kA Interrupt, HGG Frame, Thermal Magnetic Trip, 3 Poles, 3-Phase, Cable In/Out/Line/Load Lug, 8 to 1/0 AWG Al/Cu Wire, 40 deg C, 5.4 in H x 3 in W x 2.8 in D
Alternate Catalog Number US2:HGG3B040L ARRA Compliant C Buy American Compliant C Catalog Number HGG3B040L Connection Type Cable In/Out/Line/Load Lug Country of Origin MX Currency USD Dimensions 5.4 in H x 3 in W x 2.8 in D EU RoHS Indicator C Frame HGG Frequency Rating 50/60 Hz Gross Volume Per Pack 30.00 Gross Volume UOM in Gross Weight Per Pack 2.7500 lb Gross Weight per Pack Metric 1.25 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 5.0000 in Height [Metric] 12.7000 cm Length 3.0000 in Length [Metric] 7.6200 cm Number Of Poles 3 Phase 3 pH Returnable N Standard UL/CSA/IEC/NOM Standards UL 489CSA C22.2 Temperature Rating 40 °C Type Low Voltage UNSPSC 39121601 UPC 11 88762127875 UPC 12 887621278755 Width 2.0000 in Width [Metric] 5.0800 cm Wire Size 8 to 1/0 AWG Al/Cu Stock Status NONSTOCK Brand Siemens Manufacturer Siemens Amperage Rating 40 A Interrupt Rating 35 kA Trip Type Thermal Magnetic Voltage Rating 480 VAC GENERAL APPLICATION HGG frame with high breaking capacity
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Alternate Catalog Number | US2:HGG3B040L |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | HGG3B040L |
| Connection Type | Cable In/Out/Line/Load Lug |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 5.4 in H x 3 in W x 2.8 in D |
| EU RoHS Indicator | C |
| Frame | HGG |
| Frequency Rating | 50/60 Hz |
| Gross Volume Per Pack | 30.00 |
| Gross Volume UOM | in |
| Gross Weight Per Pack | 2.7500 lb |
| Gross Weight per Pack Metric | 1.25 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 5.0000 in |
| Height [Metric] | 12.7000 cm |
| Length | 3.0000 in |
| Length [Metric] | 7.6200 cm |
| Number Of Poles | 3 |
| Phase | 3 pH |
| Returnable | N |
| Standard | UL/CSA/IEC/NOM |
| Standards | UL 489CSA C22.2 |
| Temperature Rating | 40 °C |
| Type | Low Voltage |
| UNSPSC | 39121601 |
| UPC 11 | 88762127875 |
| UPC 12 | 887621278755 |
| Width | 2.0000 in |
| Width [Metric] | 5.0800 cm |
| Wire Size | 8 to 1/0 AWG Al/Cu |
| Stock Status | NONSTOCK |
| Brand | Siemens |
| Manufacturer | Siemens |
| Amperage Rating | 40 A |
| Interrupt Rating | 35 kA |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 480 VAC |
| GENERAL APPLICATION |
| HGG frame with high breaking capacity |
