Siemens Speedfax™ HEB3B040B Molded Case Circuit Breaker, 480 VAC, 40 A, 65 kA Interrupt, 3 Poles, Thermal Magnetic Trip
Molded Case Circuit Breakers
568826
MFG #: HEB3B040B
Siemens
8426.21000
/ ea
Siemens Panelboard mounting circuit breakers are designed for quick installation in Siemens panelboards and switchboards. The interlocking features allow for one screw installation which mounts the breaker line end bus tab to the panelboard bus bar. Ideally suited for use in lighting panels, these breakers offer HACR ratings as well as switching duty ratings for 15 to 20 A and HID ratings from 15 to 50 A
- Catalog URL - Siemens_B11000S01_Catalog.pdf(Catalog URL)
- Computer~Aided [CAD|BIM] Model URL - SIE_DW_EB-1Pole-2Pole-3Pole-Breaker.dwg(Computer~Aided [CAD|BIM] Model URL)
- http://www.sea.siemens.com(Seller Home Page URL)
- Spec Sheet URL - DatasheetService?format=PDF&caller=EGH&mlfbs=US2:HEB3B040B&language=en(Spec Sheet URL)
- Spec Sheet URL - DatasheetService?format=PDF&caller=PDPS&mlfbs=US2:HEB3B040B&language=en(Spec Sheet URL)
- Spec Sheet URL - sf-11-sect-07-029-036.pdf(Spec Sheet URL)
- User Manual URL - man(User Manual URL)
- User Manual URL - SIE_IS_EB-Fr_Mounting-Instructions.pdf(User Manual URL)
- Features
| PANELBOARD MOUNTING |
| Load end standard copper aluminum lugs |
| Long time and instantaneous trip functions |
| Global interchangeable |
