Siemens Speedfax™ BQ3B090 Molded Case Circuit Breaker, 240 VAC, 90 A, 10 kA Interrupt, 3 Poles, Thermal Magnetic Trip
Molded Case Circuit Breakers
92867
MFG #: BQ3B090
Siemens
713.69000
/ ea
Circuit breakers provide a manual means of energizing and de-energizing a circuit. In addition, circuit breakers provide automatic over current protection of a circuit. A circuit breaker allows a circuit to be reactivated quickly after a short circuit or overload is cleared. Unlike fuses, which must be replaced when they open, a simple flip of the breaker's operating handle restores the circuit.
- Catalog URL - Siemens_HHED63B015A_Catalog.pdf(Catalog URL)
- http://www.sea.siemens.com(Seller Home Page URL)
- Spec Sheet URL - 10991_9YM5JV7CPSK0U26O.pdf(Spec Sheet URL)
- Spec Sheet URL - DatasheetService?format=PDF&caller=PDPS&mlfbs=US2:BQ3B090&language=en(Spec Sheet URL)
- Spec Sheet URL - 10991_NVBK95QSA3UHLG1R.pdf(Spec Sheet URL)
- Spec Sheet 1 URL - ID-SPE-v2-SF17-07-035.pdf(Spec Sheet 1 URL)
- Spec Sheet URL - SF17-07-035.pdf(Spec Sheet URL)
- User Manual URL - man(User Manual URL)
- Features
| N/A |
| Sense when an over current occurs |
| Measure the amount of over current |
| ACT by tripping quickly enough to prevent damage to itself and associated conductors |
| Lug in/lug out with insta-wire |
| 4 to 1/0 AWG copper, 2 to 1/0 AWG aluminum wire |
| 4 - 1/0 AWG copper, 2 - 1/0 AWG aluminum |
