Siemens Speedfax™ BQ2B10000S01 Molded Case Circuit Breaker, 120/240 VAC, 100 A, 10 kA Interrupt, 2 Poles
Molded Case Circuit Breakers
326669
MFG #: BQ2B10000S01
Siemens
664.36000
/ ea
Circuit breakers provide a manual means of energizing and de-energizing a circuit. In addition, circuit breakers provide automatic over current protection of a circuit. A circuit breaker allows a circuit to be reactivated quickly after a short circuit or overload is cleared. Unlike fuses, which must be replaced when they open, a simple flip of the breaker's operating handle restores the circuit.
- Catalog URL - IDW_DOCUMENT_1537663746854.pdf(Catalog URL)
- http://www.sea.siemens.com(Seller Home Page URL)
- Spec Sheet URL - DatasheetService?format=PDF&caller=EGH&mlfbs=US2:BQ2B10000S01&language=en(Spec Sheet URL)
- Spec Sheet URL - sf-11-sect-07-037-044.pdf(Spec Sheet URL)
- User Manual URL - man(User Manual URL)
- Features
Shunt Trip 120V |
Sense when an over current occurs |
Measure the amount of over current |
ACT by tripping quickly enough to prevent damage to itself and associated conductors |
Lug in/lug out with insta-wire |
4 to 1/0 AWG copper, 2 to 1/0 AWG aluminum wire |
120 VAC shunt trip |
120 V shunt trip |
