Siemens Speedfax™ B23000S01 Molded Case Circuit Breaker, 120/240 VAC, 30 A, 10 kA Interrupt, 2 Poles
Custom_Product_Images_Illustration
Siemens Speedfax™ B23000S01 Molded Case Circuit Breaker, 120/240 VAC, 30 A, 10 kA Interrupt, 2 Poles
SKU340174
MFGR #B23000S01
Your Cost: $255.33/ea
List: SIEMENS B23000S01 2P 30A CKT BRKR
SIEMENS B23000S01 2P 30A CKT BRKR
Actuator Type Toggle Alternate Catalog Number US2:B23000S01 ARRA Compliant C Buy American Compliant C Catalog Number B23000S01 Connection Type Bolt-On Country of Origin MX Currency USD Dimensions 5.4 in L x 4.3 in W x 3.8 in H EU RoHS Indicator C Frequency Rating 60 Hz Gross Volume Per Pack 35.00 Gross Volume UOM in Gross Weight Per Pack 1.1500 lb Gross Weight per Pack Metric 0.52 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 2.8900 in Height [Metric] 8.8900 cm Length 2.5720 in Length [Metric] 6.3500 cm Mounting Type Panel Number Of Poles 2 Phase 1 pH Returnable N Standard ULLISTED/CSA/NOMCERTIFIED Standards ARRA CompliantBuy American Act CompliantRoHS CompliantUL 489HACR Rated Temperature Rating 40 °C Type Type BL Low Voltage UNSPSC 39121601 UPC 11 78364326836 UPC 12 783643268364 Width 3.0000 in Width [Metric] 10.1600 cm Wire Size 14 to 6 AWG, 12 to 6 AWG Stock Status NONSTOCK Brand Siemens Manufacturer Siemens Amperage Rating 30 A Interrupt Rating 10 kA Trip Type Shunt/Thermal Magnetic Voltage Rating 120/240 VAC Shunt Trip 120V Sense when an over current occurs Measure the amount of over current Act by tripping quickly enough to prevent damage to itself and associated conductors Mounting with insta-wire 14 to 6 AWG copper, 12 to 6 AWG aluminum wire 120 VAC shunt trip
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Actuator Type | Toggle |
| Alternate Catalog Number | US2:B23000S01 |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | B23000S01 |
| Connection Type | Bolt-On |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 5.4 in L x 4.3 in W x 3.8 in H |
| EU RoHS Indicator | C |
| Frequency Rating | 60 Hz |
| Gross Volume Per Pack | 35.00 |
| Gross Volume UOM | in |
| Gross Weight Per Pack | 1.1500 lb |
| Gross Weight per Pack Metric | 0.52 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 2.8900 in |
| Height [Metric] | 8.8900 cm |
| Length | 2.5720 in |
| Length [Metric] | 6.3500 cm |
| Mounting Type | Panel |
| Number Of Poles | 2 |
| Phase | 1 pH |
| Returnable | N |
| Standard | ULLISTED/CSA/NOMCERTIFIED |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantUL 489HACR Rated |
| Temperature Rating | 40 °C |
| Type | Type BL Low Voltage |
| UNSPSC | 39121601 |
| UPC 11 | 78364326836 |
| UPC 12 | 783643268364 |
| Width | 3.0000 in |
| Width [Metric] | 10.1600 cm |
| Wire Size | 14 to 6 AWG, 12 to 6 AWG |
| Stock Status | NONSTOCK |
| Brand | Siemens |
| Manufacturer | Siemens |
| Amperage Rating | 30 A |
| Interrupt Rating | 10 kA |
| Trip Type | Shunt/Thermal Magnetic |
| Voltage Rating | 120/240 VAC |
| Shunt Trip 120V |
| Sense when an over current occurs |
| Measure the amount of over current |
| Act by tripping quickly enough to prevent damage to itself and associated conductors |
| Mounting with insta-wire |
| 14 to 6 AWG copper, 12 to 6 AWG aluminum wire |
| 120 VAC shunt trip |
